www.ittcannon.com
B–9
Dimensions shown in: mm (inch)
Specifications and dimensions subject to change
T
B
Actuator
2
Standard
KMS Series
Technical Data - Tact Switches
How To Order
Our easy build-a-switch concept allows you to mix and match options to create the switch you need. To order, select
desired option from each category and place it in the appropriate box.
Typical Applications
Mobile phones, pagers
PDAs
Medical handheld monitors
Consumer electronics
Telecommunication networks
Packaging
Switches are delivered in tape and reels of 3,000 pieces. The reel
diameter is 330 (12.992). The tape dimensions conform to the
EIA-RS-481 and EC-286-6 norms.
Note
: Specifications listed above are for switches with standard options. For information on
specific and custom switches, consult Customer Service Center.
Actuation Force
2
2 N (200 grams)
3
2.5 N (250 grams)
RoHS compliant and compatible
LFS
Lead free silver
LFG
Lead free gold
K
M
S
2
G
Contact Material
1
Silver
3
Gold
Termination
G
Gullwing
Electrical
Silver
Gold
MAXIMUM POWER:
MAXIMUM VOLTAGE:
MAXIMUM CURRENT DC:
MINIMUM CURRENT DC:
DIELECTRIC STRENGTH: 250 VDC
CONTACT RESISTANCE:
≤
100 m
INSULATION RESISTANCE: 10
9
BOUNCE TIME:
≤
3 ms
1 VA
32 VDC
50 mA
1 mA
0.2 VA
32 VDC
10 mA
1 mA
Environmental
Silver
Gold
OPERATING TEMPERATURE:
STORAGE TEMPERATURE:
-40C to 85C
-55C to 85C
-40C to 125C
-55C to 125C
Process
Compatible with infrared reflow, lead free soldering and pick and
place SMT machines.
Pegs
NONE
No pegs
P
With pegs
Features/Benefits
Compact size
Excellent tactile feel
ESD protection
Date code marking
Positioning pegs for stability
IP 40 sealing
RoHS compliant and compatible
Operating force
Newtons (grams)
2N (200)
2N (200)
2.5N (250)
2.5N (250)
Operating life
(operations)
100 K cycles
100 K cycles
100 K cycles
100 K cycles
Type
Travel
0,25
±
0,15
0,25
±
0,15
0,3
±
0,15
0,3
±
0,15
KMS221G/GP
KMS223G/GP
KMS231G/GP
KMS233G/GP
Specification
FUNCTION: Momentary
CONTACT ARRANGEMENT: SPST, N.O.
TERMINALS: Gullwing type for SMT
IP40 Sealed
