HD404328 Series
43
3
2
1
0
Port mode register C (PMRC): $012
BUZZ output frequency selection
R1 /BUZZ pin mode selection
Pull-up MOS transistor on/off selection
3
2
1
0
LCD output register (LOR): $015
PMRC
Bit 3
PMRC
Bit 3
Port
Selection
Pull-Up MOS
On/Off Selection
0
1
Off
On
0
1
R1
BUZZ
3
R2/SEG1–SEG4 pin mode selection
R3/SEG5–SEG8 pin mode selection
R4/SEG9–SEG12 pin mode selection
R5/SEG13–SEG16 pin mode selection
LOR
Bit 3
0
1
Port
Selection
Port
Selection
Port
Selection
Port
Selection
LOR
Bit 2
0
1
LOR
Bit 1
0
1
LOR
Bit 0
0
1
R5
SEG13–SEG16
R4
SEG9–SEG12
R3
SEG5–SEG8
R2
SEG1–SEG4
Initial value: 0000, R/W: W
Initial value: 0000, R/W: W
Figure 24 I/O Switching Mode Registers (cont)
Pull-Up MOS Transistor Control:
A program-controlled pull-up MOS transistor is provided for each
input/output pin. The on/off status of all these transistors is controlled by bit 3 of port mode register C
(PMRC), and the on/off status of an individual transistor can also be controlled by the port data register of
the corresponding pin—enabling on/off control of that pin alone.
The on/off status of each transistor and the peripheral function mode of each pin can be set independently.
The configuration of the I/O buffer is shown in figure 25, and the configurations of various program-
controlled I/O circuits are given in table 23.
How to Deal with Unused I/O Pins:
I/O pins that are not needed by the user system (floating) must be
connected to V
CC
to prevent LSI malfunctions due to noise. These pins must either be pulled up to V
CC
by
their pull-up MOS transistors or by resistors of about 100 k
.
