GS9062 Data Sheet
22209 - 5
May 2005
14 of 46
Serial Digital Output
Serial Output Data Rate
DR
SDO
–
–
270
–
Mb/s
1
–
Serial Output Swing
Δ
V
SDD
RSET = 281
Ω
Load = 75
Ω
–
800
–
mVp-p
1
–
Serial Output Rise Time
20% ~ 80%
tr
SDO
ORL compensation
using recommended
circuit
400
550
1500
ps
1
–
Serial Output Fall Time
20% ~ 80%
tf
SDO
ORL compensation
using recommended
circuit
400
550
1500
ps
1
–
Serial Output Intrinsic Jitter
t
IJ
Pseudorandom and
pathological signal
–
270
350
ps
1
–
Serial Output Duty Cycle
Distortion
DCD
SDO
–
–
20
–
ps
1
2
GSPI
GSPI Input Clock Frequency
f
SCLK
–
–
–
6.6
MHz
1
–
GSPI Input Clock Duty Cycle
DC
SCLK
–
40
50
60
%
6,7
–
GSPI Input Data Setup Time
–
0
–
–
ns
6,7
–
GSPI Input Data Hold Time
–
1.43
–
–
ns
6,7
–
GSPI Output Data Hold Time
–
2.10
–
–
ns
6,7
–
GSPI Output Data Delay Time
–
–
–
7.27
ns
6,7
–
TEST LEVELS
1. Production test at room temperature and nominal supply voltage with
guardbands for supply and temperature ranges.
2. Production test at room temperature and nominal supply voltage with
guardbands for supply and temperature ranges using correlated test.
3. Production test at room temperature and nominal supply voltage.
4. QA sample test.
5. Calculated result based on Level 1, 2, or 3.
6. Not tested. Guaranteed by design simulations.
7. Not tested. Based on characterization of nominal parts.
8. Not tested. Based on existing design/characterization data of similar
product.
9. Indirect test.
NOTES
1. With 15pF load.
2. Serial Duty Cycle Distortion is defined here to be the
difference between the width of a ‘1’ bit, and the width of a
‘0’ bit.
3. See
Device Power Up on page 41
,
Figure 3-12
.
Table 2-2: AC Electrical Characteristics (Continued)
T
A
= 0°C to 70°C, unless otherwise shown
Parameter
Symbol
Conditions
Min
Typ
Max
Units
Test
Levels
Notes
