| 型號： | EHP-A09/CT01H-PU5 |
| 廠商： | EVERLIGHT ELECTRONICS CO LTD |
| 元件分類： | LED |
| 英文描述： | SINGLE COLOR LED, COOL WHITE |
| 封裝： | ROHS COMPLIANT, SMT, 6 PIN |
| 文件頁數： | 6/12頁 |
| 文件大?。?/td> | 209K |
| 代理商： | EHP-A09/CT01H-PU5 |
EVERLIGHT ELECTRONICS CO.,LTD.
EHP-A09/CT01H-PU5
Everlight Electronics Co., Ltd.
http://www.everlight.com
Rev. 1.0
Page: 3/12
Device No. : DSE-A09-010
Prepared date: May. 07, 2008
Prepared by: Kenny Chen
Maximum Ratings (T Ambient=25C)
Parameter
Symbol
Rating
Unit
DC Operating Current
IF
150
mA
Pulsed Forward Current
IPF
300
mA
ESD Sensitivity
ESD
2000
V
Junction Temperature
Tj
125
°C
Operating Temperature
Topr
-40 ~ +85
°C
Storage Temperature
Tstg
-40 ~ +100
°C
Power Dissipation
Pd
0.5
W
Junction To Heat-Sink Thermal Resistance
Rth
50
K/W
Electro-Optical Characteristics (TAmbient=25C)
Parameter
Bin
Symbol
Min
Typ.
Max
Unit
Condition
D2
5600
----
7100
E1
7100
----
9000
Luminous Intensity(1)
E2
Iv
9000
----
11200
mcd
V1
2.95
----
3.25
V2
3.25
----
3.55
Forward Voltage(2)
V3
VF
3.55
----
3.85
V
Viewing Angle(3)
----
2θ1/2
----
120
----
deg
Color Temperature(4)
----
CCT
4600
5600
15000
K
IF=150mA
Note. 1. Luminous Intensity measurement tolerance: ±10%
2. Forward Voltage measurement tolerance: ±0.1V
3.
2θ1/2 is the off axis angle from lamp centerline where the luminous intensity is 1/2 of the peak value.
