EVERLIGHT ELECTRONICS CO.,LTD.
EHP-A09/CT01H-PU5
Everlight Electronics Co., Ltd.
http://www.everlight.com
Rev. 1.0
Page: 10/12
Device No. : DSE-A09-010
Prepared date: May. 07, 2008
Prepared by: Kenny Chen
Reliability Test Items
Stress Test
Stress Condition
Stress Duration
Reflow
Tsol=260°C, 10sec, 6min(total)
2 times
DC Operating Life
Ta=25°C , IF=150mA
1000 hours
High Temperature Storage
Ta=100°C
1000 hours
High Temperature Operation Life #1
Ta=55°C, IF=150mA
1000 hours
High Temperature Operation Life #2
Ta=85℃, I
F=120mA
1000hours
Low Temperature Storage
Ta=-40°C
1000 hours
High Temperature/
Humidity Reverse Bias
Ta=85℃ , RH=85%
1000hours
High Temperature/
Humidity Operation Life
Ta=85°C , RH=60%, IF=120mA
1000 hours
Temperature Cycle
H：＋100°C 15min.
'∫ 5min.
'L：－40°C
15min.
300 Cycles
Power Temperature Cycle
H：＋85°C 15min.
'∫ 5min.
'L：－40°C
15min. , I
F=120mA
1000 Cycles
Thermal Shock
H：＋110°C 5min.
'∫ 10sec.
'L：－40°C
5min.
300 Cycles
Pulse Test
Ta=25℃, IF=1000mA
30mS on/ 2500mS off
30000 times
ESD Human Body Model
2000V, Interval:0.5sec
3 times
ESD Machine Model
200V, Interval:0.5sec
3 times
*lm: Brightness attenuate difference(1000hrs)＜50%
*
VF: Forward voltage difference＜20%
Notes: All reliability items are tested under superior thermal management with 1.5 x 1.5 cm
2 MCPCB.
