參數資料
型號： ATTINY13V-10SSUR
廠商： Atmel
文件頁數： 103/176頁
文件大?。?/td> 0K
描述： MCU AVR 1KB FLASH 10MHZ 8SOIC
產品培訓模塊： tinyAVR Introduction
標準包裝： 4,000
系列： AVR® ATtiny
核心處理器： AVR
芯體尺寸： 8-位
速度： 10MHz
外圍設備： 欠壓檢測/復位，POR，PWM，WDT
輸入/輸出數： 6
程序存儲器容量： 1KB（512 x 16）
程序存儲器類型： 閃存
EEPROM 大小： 64 x 8
RAM 容量： 64 x 8
電壓 - 電源 (Vcc/Vdd)： 1.8 V ~ 5.5 V
數據轉換器： A/D 4x10b
振蕩器型： 內部
工作溫度： -40°C ~ 85°C
封裝/外殼： 8-SOIC（0.154"，3.90mm 寬）
包裝： 帶卷 (TR)
其它名稱： ATTINY13V-10SSUR-ND
ATTINY13V-10SSURTR
32
2535J–AVR–08/10
ATtiny13
7.2.4
Internal Voltage Reference
The Internal Voltage Reference will be enabled when needed by the Brown-out Detection, the
Analog Comparator or the ADC. If these modules are disabled as described in the sections
above, the internal voltage reference will be disabled and it will not be consuming power. When
turned on again, the user must allow the reference to start up before the output is used. If the
reference is kept on in sleep mode, the output can be used immediately. Refer to “Internal Volt-
age Reference” on page 37 for details on the start-up time.
7.2.5
Watchdog Timer
If the Watchdog Timer is not needed in the application, this module should be turned off. If the
Watchdog Timer is enabled, it will be enabled in all sleep modes, and hence, always consume
power. In the deeper sleep modes, this will contribute significantly to the total current consump-
tion. Refer to “Interrupts” on page 44 for details on how to configure the Watchdog Timer.
7.2.6
Port Pins
When entering a sleep mode, all port pins should be configured to use minimum power. The
most important thing is then to ensure that no pins drive resistive loads. In sleep modes where
both the I/O clock (clkI/O) and the ADC clock (clkADC) are stopped, the input buffers of the device
will be disabled. This ensures that no power is consumed by the input logic when not needed. In
some cases, the input logic is needed for detecting wake-up conditions, and it will then be
enabled. Refer to the section “Digital Input Enable and Sleep Modes” on page 52 for details on
which pins are enabled. If the input buffer is enabled and the input signal is left floating or has an
analog signal level close to VCC/2, the input buffer will use excessive power.
For analog input pins, the digital input buffer should be disabled at all times. An analog signal
level close to VCC/2 on an input pin can cause significant current even in active mode. Digital
input buffers can be disabled by writing to the Digital Input Disable Register (DIDR0). Refer to
7.3
Register Description
7.3.1
MCUCR – MCU Control Register
The MCU Control Register contains control bits for power management.
Bit 5 – SE: Sleep Enable
The SE bit must be written to logic one to make the MCU enter the sleep mode when the SLEEP
instruction is executed. To avoid the MCU entering the sleep mode unless it is the programmer’s
purpose, it is recommended to write the Sleep Enable (SE) bit to one just before the execution of
the SLEEP instruction and to clear it immediately after waking up.
Bit
7
654
32
10
–
PUD
SE
SM1
SM0
—
ISC01
ISC00
MCUCR
Read/Write
R
R/W
R
R/W
Initial Value
0
