| 型號： | APS3605RS26Q1 |
| 廠商： | ANADIGICS INC |
| 元件分類： | 分路器/合路器 |
| 英文描述： | 50 MHz - 1000 MHz RF/MICROWAVE SPLITTER |
| 封裝： | 3 X 3 MM, 1 MM HEIGHT, ROHS COMPLIANT, MO-220, S26, QFN-12 |
| 文件頁數： | 1/12頁 |
| 文件大?。?/td> | 355K |
| 代理商： | APS3605RS26Q1 |
07/2008
APS3605
1 GHz Three-way Active Power Splitter
PRELIMINARY DATA SHEET - Rev 1.4
S26 Package
12 Pin QFN
3 mm x 3 mm x 1 mm
FEATURES
SingleInput,TripleOutputDesign
WidebandOperationBeyond1GHz
SupportsbothAnalogTVandDigitalTVLineups
Nominal3dBGain
5.5dBTypicalNoiseFigure
Single+5VSupply,withOperationDownto+3.3V
HighLinearity,LowDistortion
CurrentAdjustPinforoptimizingdistortion
performance
Single-Ended75OhmInputs/Outputs
RoHSCompliantPackage
APPLICATIONS
Analog/DigitalandAll-DigitalCATVSet-TopBoxes
withMultipleTuners
Multiple-TunerTVs,TVTunerCardsand
BroadbandMediaCenters
PRODUCT DESCRIPTION
ThisAPS3605activesplitterfromANADIGICSaccepts
abroadbandRFinputfrom50MHzto1GHzandsplits
thesignaltoprovidethreebroadbandRFoutputswith
minimal degradation of quality.The single-package
surfacemountdeviceamplifiestheinputusinghighly
linear,lownoiseamplificationstages,andcouplesthe
amplifiedsignaltothreeseparateoutputpathsthat
eachcandriveeitheranalogvideo,digitalvideoor
digitaldatatuners.Theoveralllinearityofeachpath
ismaintainedacrosstheentireoperatingfrequency
Figure 1: Functional Block Diagram
range,ensuringlowdistortioneffectsoneachoutput
signal.
Requiringasinglevoltagesupplyof+5V,andoperable
downto+3.3V,theactivesplitterismanufactured
usingANADIGICS’ highly reliable GaAs MESFET
process.The small surface mount QFN packaging
makes this device ideal for use in today’s set-top
boxes, televisions and video tuner cards requiring
multiple-tunersolutions.
RF Input
RF Output 1
RF Output 2
GND
RF Output 3
Current
Adjust
APS3605
