Table 2. DC Specifications
(Vdd = 7V, Vg2 = Open, TA = 25°C, otherwise specified)
Symbol
Parameters and Test Conditions
Unit
Minimum
Typical
Maximum
Vdd
Recommended Drain Supply Voltage
V
-
7
-
Idd
Total Drain Supply Current (Vg1 set for typical
Idd)
mA
-
200
-
Vg1
First Gate Voltage (Vdd = 7V, Idd = 200mA)
V
-3.5
-3.0
-2.5
Idss
Saturated Drain Current (Vg1 = 0V)
mA
-
350
-
Idsmin (Vg1)
First Gate Minimum Drain Current (Vg1 = -7V) mA
-
80
-
qch-b
Thermal Resistance [1]
°C/W
-
16.2
-
Note:
1. Channel-to-board Thermal Resistance is measured using QFI method.
Table 3. RF Specifications [1]
(Freq = 22GHz, Vdd = 7V, Idd = 200mA, TA = 25°C, Zin = Zo = 50Ohm)
Symbol
Parameters and Test Conditions
Unit
Minimum
Typical
Maximum
Gain
Small Signal Gain [2]
dB
12.5
14.8
16.5
ISO
Reverse Isolation
dB
-
30
-
RLin
Input Return Loss
dB
-
13
-
RLout
Output Return Loss
dB
-
14
-
NF
Noise Figure
dB
-
4.6
-
P1dB
Output Power at 1dB Gain Compression
dBm
-
22
-
OIP3
Output 3rd Order Intercept Point [3]
dBm
-
25
-
Notes:
1. Specifications are derived from measurements in a 50 Ohm test environment. Aspects of the amplifier performance may be improved over a
narrower bandwidth by application of additional conjugate, linearity, or low noise matching.
2. All tested parameters guaranteed with measurement accuracy ± 0.5 dB for gain.
3. RFin1 = RFin2 = -5 dBm, Freq = 22GHz, Df = 100MHz
Table 4. RF Specifications [1]
(Freq = 22GHz, Vdd = 4V, Idd = 160mA, TA = 25°C, Zin = Zo = 50Ohm)
Symbol
Parameters and Test Conditions
Unit
Minimum
Typical
Maximum
Gain
Small signal Gain
dB
-
15
-
ISO
Reverse Isolation
dB
-
27
-
RLin
Input Return Loss
dB
-
13
-
RLout
Output Return Loss
dB
-
14
-
NF
Noise Figure
dB
-
4.6
-
P1dB
Output Power at 1dB Gain Compression
dBm
-
19
-
OIP3
Output 3rd Order Intercept Point [3]
dBm
-
18.5
-
Notes:
1. Specifications are derived from measurements in a 50 Ohm test environment. Aspects of the amplifier performance may be improved over a
narrower bandwidth by application of additional conjugate, linearity, or low noise matching.
2. RFin1 = RFin2 = -5 dBm, Freq = 22GHz, Df = 100MHz
