| 型號： | ADV7604BBCZ-5P |
| 廠商： | Analog Devices Inc |
| 文件頁數： | 4/20頁 |
| 文件大?。?/td> | 0K |
| 描述： | IC DIGITIZER VID/GRAPHIC 260BGA |
| 標準包裝： | 1 |
| 系列： | Advantiv® |
| 類型： | 視頻數字轉換器 |
| 應用： | HDTV |
| 安裝類型： | 表面貼裝 |
| 封裝/外殼： | 260-LFBGA，CSBGA |
| 供應商設備封裝： | 260-CSPBGA（15x15） |
| 包裝： | 托盤 |
第1頁第2頁第3頁當前第4頁第5頁第6頁第7頁第8頁第9頁第10頁第11頁第12頁第13頁第14頁第15頁第16頁第17頁第18頁第19頁第20頁
ADV7604
Data Sheet
Rev. D | Page 12 of 20
Pin No.
Mnemonic
Type
Description
D11
CVDD
Power
Comparator Supply Voltage (1.8 V).
D12
DDCB_SDA
HDMI input
HDCP Slave Serial Data Port B. DDCB_SDA is a 3.3 V input that is 5 V tolerant.
D13
DDCB_SCL
HDMI input
HDCP Slave Serial Clock Port B. DDCB_SCL is a 3.3 V input that is 5 V tolerant.
D14
DDCA_SCL
HDMI input
HDCP Slave Serial Clock Port A. DDCA_SCL is a 3.3 V input that is 5 V tolerant.
D15
DDCA_SDA
HDMI input
HDCP Slave Serial Data Port A. DDCA_SDA is a 3.3 V input that is 5 V tolerant.
D16
TVDD
Power
Terminator Supply Voltage (3.3 V).
D17
RXA_0+
HDMI input
Digital Input Channel 0 Complement of Port A in the HDMI Interface.
D18
RXA_0
HDMI input
Digital Input Channel 0 Complement of Port A in the HDMI Interface.
E1
DE
Digital video output
Data Enable. DE is a signal that indicates active pixel data.
E2
CEC
Digital I/O
Consumer Electronic Control Channel.
E3
NC
No connect
Do Not Connect.
E4
NC
No connect
Do Not Connect.
E15
DGND
Ground
Ground.
E16
DGND
Ground
Ground.
E17
RXA_C+
HDMI input
Digital Input Clock Complement of Port A in the HDMI Interface.
E18
RXA_C
HDMI input
Digital Input Clock Complement of Port A in the HDMI Interface.
F1
HS
Digital video output
Horizontal Synchronization Output Signal in the CP and HDMI Processor.
F2
VS_FIELD
Digital video output
Vertical Synchronization Output Signal in the CP and HDMI Processor. FIELD is a
field synchronizationoutput signal in all interlaced video modes. VS or FIELD
can be configured for this pin.
F3
EP_MISO
Digital input
SPI Master In/Slave Out for External EDID Interface.
F4
EP_MOSI
Digital output
SPI Master Out/Slave In for External EDID Interface.
F15
DGND
Ground
Ground.
F16
CVDD
Power
Comparator Supply Voltage (1.8 V).
F17
TVDD
Power
Terminator Supply Voltage (3.3 V).
F18
DGND
Ground
Ground.
G1
P1
Digital video output
Video Pixel Output Port.
G2
P0
Digital video output
Video Pixel Output Port.
G3
EP_CS
Digital output
SPI Chip Select for External EDID Interface.
G4
EP_SCK
Digital output
SPI Clock for External EDID Interface.
G7
DGND
Ground
Ground.
G8
DGND
Ground
Ground.
G9
DGND
Ground
Ground.
G10
DGND
Ground
Ground.
G11
PVDD
Power
PLL Supply Voltage (1.8 V).
G12
PVDD
Power
PLL Supply Voltage (1.8 V).
G15
NC
No connect
Do Not Connect.
G16
NC
No connect
Do Not Connect.
G17
TEST1
Test
Do Not Connect.
G18
TEST2
Test
Do Not Connect.
H1
P3
Digital video output
Video Pixel Output Port.
H2
P2
Digital video output
Video Pixel Output Port.
H3
RAW_VSYNC
Analog output
This pin outputs the raw-sliced, embedded CSYNC or raw digital HS/CS.
H4
RAW_SYNC
Analog output
This pin outputs the raw-sliced, embedded CSYNC or raw digital HS/CS.
H7
DGND
Ground
Ground.
H8
DGND
Ground
Ground.
H9
DGND
Ground
Ground.
H10
DGND
Ground
Ground.
H11
AGND
Ground
Ground.
H12
AGND
Ground
Ground.
