- 您現在的位置：買賣IC網 > PDF目錄25570 > 9UMS9610CKLFT (INTEGRATED DEVICE TECHNOLOGY INC) 166.67 MHz, PROC SPECIFIC CLOCK GENERATOR, PQCC48 PDF資料下載
參數資料
| 型號： | 9UMS9610CKLFT |
| 廠商： | INTEGRATED DEVICE TECHNOLOGY INC |
| 元件分類： | 時鐘產生/分配 |
| 英文描述： | 166.67 MHz, PROC SPECIFIC CLOCK GENERATOR, PQCC48 |
| 封裝： | 6 X 6 MM, 0.40 MM PITCH, ROHS COMPLIANT, PLASTIC, MLF-48 |
| 文件頁數： | 3/20頁 |
| 文件大小： | 134K |
| 代理商： | 9UMS9610CKLFT |
IDTTM/ICSTM PC MAIN CLOCK
1336—06/01/09
ICS9UMS9610
PC MAIN CLOCK
11
Byte
2
Output Enable Register
Bit(s)
Pin #
Name
Description
Type
0
1
Default
7
CPU0 Enable
This bit controls whether the CPU[0] output
buffer is enabled or not.
RW
0 = Disabled
1 = Enabled
1
6
CPU1 Enable
This bit controls whether the CPU[1] output
buffer is enabled or not.
RW
0 = Disabled
1 = Enabled
1
5
CPU2 Enable
This bit controls whether the CPU[2] output
buffer is enabled or not.
RW
0 = Disabled
1 = Enabled
1
4
SRC0 Enable
This bit controls whether the SRC[0] output
buffer is enabled or not.
RW
0 = Disabled
1 = Enabled
1
3
SRC1 Enable
This bit controls whether the SRC[1] output
buffer is enabled or not.
RW
0 = Disabled
1 = Enabled
1
2
SRC2 Enable
This bit controls whether the SRC[2] output
buffer is enabled or not.
RW
0 = Disabled
1 = Enabled
1
DOT Enable
This bit controls whether the DOT output
buffer is enabled or not.
RW
0 = Disabled
1 = Enabled
1
0
LCD100 Enable
This bit controls whether the LCD output buffer
is enabled or not.
RW
0 = Disabled
1 = Enabled
1
Byte
3
Output Control Register
Bit(s)
Pin #
Name
Description
Type
0
1
Default
7
Reserved
0
6
Reserved
0
5
REF Enable
This bit controls whether the REF output
buffer is enabled or not.
RW
0 = Disabled
1 = Enabled
1
4
3
2
CPU0 Stop
Enable
This bit controls whether the CPU[0] output
buffer is free-running or stoppable. If it is set
to stoppable the CPU[0] output buffer will be
disabled with the assertion of CPU_STP#.
RW
Free Running
Stoppable
0
1
CPU1 Stop
Enable
This bit controls whether the CPU[1] output
buffer is free-running or stoppable. If it is set
to stoppable the CPU[1] output buffer will be
disabled with the assertion of CPU_STP#.
RW
Free Running
Stoppable
0
CPU2 Stop
Enable
This bit controls whether the CPU[2] output
buffer is free-running or stoppable. If it is set
to stoppable the CPU[2] output buffer will be
disabled with the assertion of CPU_STP#.
RW
Free Running
Stoppable
0
10
00 = Slow Edge Rate
01 = Medium Edge Rate
10 = Fast Edge Rate
11 = Reserved
RW
These bits control the edge rate of the REF
clock.
REF Slew
