74VCXH16373
http://onsemi.com
3
TRUTH TABLE
Inputs
Outputs
Inputs
Outputs
LE1
OE1
D0:7
O0:7
LE2
OE2
D8:15
O8:15
X
H
X
Z
X
H
X
Z
H
L
L
L
H
L
L
L
H
L
H
H
H
L
H
H
L
L
X
O0
L
L
X
O0
H = High Voltage Level
L = Low Voltage Level
Z = High Impedance State
X = High or Low Voltage Level and Transitions Are Acceptable, for I
CC
reasons, DO NOT FLOAT Inputs.
O0 = No Change.
ABSOLUTE MAXIMUM RATINGS
Symbol
Parameter
Value
Condition
Unit
V
CC
DC Supply Voltage
0.5 to +4.6
V
V
I
DC Input Voltage
0.5
≤
V
I
≤
+4.6
V
V
O
DC Output Voltage
0.5
≤
V
O
≤
+4.6
Output in 3
State
V
0.5
≤
V
O
≤
V
CC
+ 0.5
Note 1; Outputs Active
V
I
IK
DC Input Diode Current
50
V
I
< GND
mA
I
OK
DC Output Diode Current
50
V
O
< GND
mA
+50
V
O
> V
CC
mA
I
O
DC Output Source/Sink Current
±
50
mA
I
CC
DC Supply Current Per Supply Pin
±
100
mA
I
GND
DC Ground Current Per Ground Pin
±
100
mA
T
STG
Stresses exceeding Maximum Ratings may damage the device. Maximum Ratings are stress ratings only. Functional operation above the
Recommended Operating Conditions is not implied. Extended exposure to stresses above the Recommended Operating Conditions may affect
device reliability.
1. I
O
absolute maximum rating must be observed.
Storage Temperature Range
65 to +150
°
C
RECOMMENDED OPERATING CONDITIONS
Symbol
Parameter
Min
Typ
Max
Unit
V
CC
Supply Voltage
Operating
Data Retention Only
1.65
1.2
3.3
3.3
3.6
3.6
V
V
I
Input Voltage
0.3
3.6
V
V
O
Output Voltage
(Active State)
(3
State)
0
0
V
CC
3.6
V
I
OH
HIGH Level Output Current, V
CC
= 3.0 V
3.6 V
24
mA
I
OL
LOW Level Output Current, V
CC
= 3.0 V
3.6 V
24
mA
I
OH
HIGH Level Output Current, V
CC
= 2.3 V
2.7 V
18
mA
I
OL
LOW Level Output Current, V
CC
= 2.3 V
2.7 V
18
mA
I
OH
HIGH Level Output Current, V
CC
= 1.65 V
1.95 V
6
mA
I
OL
LOW Level Output Current, V
CC
= 1.65 V
1.95 V
6
mA
T
A
Operating Free
Air Temperature
40
+85
°
C
t/ V
Input Transition Rise or Fall Rate, V
IN
from 0.8 V to 2.0 V, V
CC
= 3.0 V
0
10
ns/V
