MICROCIRCUIT DATA SHEET
MNCLC420B-X REV 1A0
(Absolute Maximum Ratings)
(Note 1)
Supply Voltage (V+)
+7 Vdc
Output Current (Iout)
70 mA
Common Mode Input Voltage (Vcm)
V+
Differential Input Voltage
10 V
Power Dissipation (Pd)
(Note 2)
112 mW
Thermal Resistance
(ThetaJA) Junction to Ambient
125 C/W
Ceramic DIP
(Still Air)
72 C/W
(500 LFPM)
100 C/W
LCC
(Still Air)
68 C/W
(500 LFPM)
(ThetaJC) Junction to Case
23 C/W
Ceramic DIP
25 C/W
LCC
Junction Temperature (Tj)
+175 C
Storage Temperature Range
-65 C < Ta < +150 C
Lead Temperature
+300 C
(Soldering, 10 seconds)
Package Weight
(Typical)
1075 mg
Ceramic DIP
470 mg
LCC
ESD Tolerance
(Note 3)
2000V
ESD Rating
Note 1:
Absolute Maximum Ratings are limits beyond which damage to the device may occur.
Operating Ratings are conditions for which the device is functional, but do not
guarantee specific performance limits.
For guaranteed specifications and test
conditions see the Electrical Characteristics.
The guaranteed specifications apply
only for the test conditions listed.
Some performance characteristics may degrade
when the device is not operated under the listed test conditions.
Note 2:
The maximum power dissipation must be derated at elevated temperatures and is
dictated by Tjmax (maximum junction temperature), ThetaJA (package junction to
ambient thermal resistance), and TA (ambient temperature).
The maximum allowable
power dissipation at any temperature is Pdmax = (Tjmax - TA)/ThetaJA or the number
given in the Absolute Maximum Ratings, whichever is lower.
Note 3:
Human body model, 100pF discharged through 1.5K Ohms.
3
