| 型號： | 5962-9175802M2A |
| 廠商： | NATIONAL SEMICONDUCTOR CORP |
| 元件分類： | 運算放大器 |
| 英文描述： | OP-AMP, 1800 uV OFFSET-MAX, CQCC20 |
| 封裝： | LCC-20 |
| 文件頁數： | 1/15頁 |
| 文件大?。?/td> | 181K |
| 代理商： | 5962-9175802M2A |
Original Creation Date: 04/07/98
Last Update Date: 05/22/00
Last Major Revision Date: 09/22/99
MNCLC420B-X REV 1A0
MICROCIRCUIT DATA SHEET
HIGH SPEED, VOLTAGE FEEDBACK OPERATIONAL AMPLIFIER
General Description
The CLC420B is an operational amplifier designed for applications requiring matched inputs
and integration or transimpedance amplification.
Utilizing voltage feedback architecture,
the CLC420B offers a 300MHz bandwidth, a 1100V/us slew rate and a 4mA supply current
(power consumption of 40mW, +5V supplies).
Additional benefits of the CLC420B are a 0.5mV
input offset voltage and a 4uV/C temperature coefficient.
Applications such as differential amplifiers will benefit from 70dB common mode rejection
ratio and an input offset current of 0.2uA(typ).
With its unity-gain stability,
2pA/SqRtHz current noise(typ), combined with a settling time of 18ns to 0.01% make the
CLC420B ideal for D/A converters, pin diode receivers and photo multiplier amplifiers.
All applications will find 70dB power supply rejection ratio attractive.
NS Part Numbers
CLC420BE-QML
CLC420BJ-QML
Industry Part Number
CLC420B
Prime Die
UB1366A
Controlling Document
SEE FEATURES SECTION
Processing
MIL-STD-883, Method 5004
Quality Conformance Inspection
MIL-STD-883, Method 5005
Subgrp Description
Temp ( C)
o
1
Static tests at
+25
2
Static tests at
+125
3
Static tests at
-55
4
Dynamic tests at
+25
5
Dynamic tests at
+125
6
Dynamic tests at
-55
7
Functional tests at
+25
8A
Functional tests at
+125
8B
Functional tests at
-55
9
Switching tests at
+25
10
Switching tests at
+125
11
Switching tests at
-55
1
