Features
The ac performance of the TLE2027 and TLE2037 is highlighted by a typical unity-gain
bandwidth specification of 15 MHz, 55° of phase margin, and noise voltage specifications of
3.3 nV/ Hz\ and 2.5 nV/ Hz\ at frequencies of 10 Hz and 1 kHz respectively. The
TLE2037 and TLE2037A have been decompensated for faster slew rate (-7.5 V/us, typical)
and wider bandwidth (50 MHz). To ensure stability, the TLE2037 and TLE2037A should be
operated with a closed-loop gain of 5 or greater.
Both the TLE20x7 and TLE20x7A are available in a wide variety of packages, including the
industry-standard 8-pin small-outline version for high-density system applications. The C-
suffix devices are characterized for operation from 0°C to 70°C. The I-suffix devices are
characterized for operation from -40°C to 105°C. The M-suffix devices are characterized for
operation over the full military temperature range of -55°C to 125°C.
l
Outstanding Combination of dc Precision and AC Performance:
Unity-Gain Bandwidth...15 MHz Typ
V
n ... 3.3 nV/
Hz\ at f = 10 Hz Typ,
2.5 nV/
Hz\ at f = 1 kHz Typ
V
IO ... 25 uV Max
A
VD ... 45 V/uV Typ With RL = 2 k
,
19 V/uV Typ With R
L = 600
l
Available in Standard-Pinout Small-Outline Package
l
Output Features Saturation Recovery Circuitry
l
Macromodels and Statistical information
features
l
Maximum positive output voltage swing
l
Maximum negative output voltage swing
l
Slew rate
l
Quiescent power dissipation
l
Input bias current
l
Open-loop voltage amplification
l
Gain-bandwidth product
l
Common-mode rejection ratio
l
Phase margin
l
DC output resistance
l
AC output resistance
l
Short-circuit output current limit
TLE2027, TLE2037, TLE2027A,
TLE2037A, TLE2027Y, TLE2037Y
