TECHNICAL DATA SHEET
RPC-2.40
PANEL PLUG
09S421-271S3
Rosenberger Hochfrequenztechnik GmbH & Co. KG
Tel.: +49 8684 18-0
Page
P.O.Box 1260
D-84526 Tittmoning
Germany
Fax: +49 8684 18-499
www.rosenberger.de
email: info@rosenberger.de
2 / 2
R
F
_
3
5
/1
2
.0
4
/3
.0
f(GHz)
Electrical data
Impedance
50
Frequency
DC to 50 GHz
Return loss
≥ 23 dB, DC to 50 GHz
Insertion loss
≤ 0.05 x
dB
Insulation resistance
≥ 5 G
Center contact resistance
≤ 4.0 m
Outer contact resistance
≤ 2.5 m
Test voltage
500 V rms
Working voltage
150 V rms
RF-leakage
≥ 100 dB up to 1 GHz
- Limitations are possible due to the used cable type -
Mechanical data
Mating cycles
≥ 500
Center contact captivation
≥ 20 N
Coupling test torque
1.65 Nm
Recommended torque
0.80 Nm to 1.10 Nm
Environmental data
Temperature range
-40°C to +85°C
Thermal shock
IEC 61169-1, Subclause 9.4.4
Corrosion
IEC 61169-1, Subclause 9.4.6
Vibration
IEC 61169-1, Subclause 9.3.3
Shock
IEC 61169-1, Subclause 9.3.14
Moisture resistance
IEC 61169-1, Subclause 9.4.3
Tooling
N/A
Suitable cables
UT 85 / RTK-FS 085 / RTK-Flex 405
Packing
Standard
1 pce in bag
Weight
10.6 g/pce
Draft
Date
Approved
Date
Rev.
Engineering change number
Name
Date
Herbert Babinger
28/04/05
Armin Maiwaelder
28/04/05
a00
04-0130
Herbert Babinger
28/04/05
While the information has been carefully compiled to the best of our knowledge, nothing is intended as representation or warranty on
our part and no statement herein shall be construed as recommendation to infringe existing patents. In the effort to improve our
products, we reserve the right to make changes judged to be necessary.
