TECHNICAL DATA SHEET
RPC-2.40
50
LOAD PLUG
09S150-C10S3
Rosenberger Hochfrequenztechnik GmbH & Co. KG
Tel.: +49 8684 18-0
Page
P.O.Box 1260
D-84526 Tittmoning
Germany
Fax: +49 8684 18-499
www.rosenberger.de
email: info@rosenberger.de
2 / 2
RF_35/12.04/3.0
Electrical data
Impedance
50
± 0.25
Frequency
DC to 50 GHz
Return loss
≥ 36 dB, DC to 4 GHz
≥ 30 dB, 4 GHz to 20 GHz
≥ 26 dB, 20 GHz to 26.5 GHz
≥ 22 dB, 26.5 GHz to 50 GHz
Center contact resistance
≤ 4.0 m
Outer contact resistance
≤ 2.5 m
Power handling
0.5 W
Mechanical data
Mating cycles
≥ 500
Center contact captivation
≥ 20 N
Coupling test torque
1.65 Nm
Recommended torque
0.80 Nm to 1.10 Nm
Gauge
0.00 – 0.05
Environmental data
Temperature range
0°C to +50°C
Tooling
N/A
Suitable cables
N/A
Packing
Standard
1 pce in bag
Weight
6.0 g/pce
Draft
Date
Approved
Date
Rev.
Engineering change number
Name
Date
Kerstin Herzog
26/09/05
Frank Wei
4/10/05
a00
04-0130
Siegmar Hoyer
05/10/05
While the information has been carefully compiled to the best of our knowledge, nothing is intended as representation or warranty on
our part and no statement herein shall be construed as recommendation to infringe existing patents. In the effort to improve our
products, we reserve the right to make changes judged to be necessary.
