TECHNICAL DATA SHEET
RPC-2.40
SHORT CIRCUIT PLUG
09S12S-000S3
Rosenberger Hochfrequenztechnik GmbH & Co. KG
Tel.: +49 8684 18-0
Page
P.O.Box 1260
D-84526 Tittmoning
Germany
Fax: +49 8684 18-499
www.rosenberger.de
email: info@rosenberger.de
2 / 2
R
F
_
3
5
/1
1
.0
5
/3
.1
Electrical data
Frequency
DC to 50 GHz
Return loss
≤ 0.15 dB, DC to 4 GHz
≤ 0.25 dB, 4 GHz to 50 GHz
Center contact resistance
≤ 4.0 m
Outer contact resistance
≤ 2.5 m
Deviation from nominal phase *
≤ 1.5°, DC to 4 GHz
≤ 4.5°, 4 GHz to 50 GHz
* The specifications are given as allowed deviation from the nominal model as defined in the test report
Mechanical data
Mating cycles
≥ 500
Center contact captivation
≥ 20 N
Coupling test torque
1.65 Nm
Recommended torque
0.80 Nm to 1.10 Nm
Environmental data
Temperature range
-40°C to +85°C
Thermal shock
IEC 61169-1, Subclause 9.4.4
Corrosion
IEC 61169-1, Subclause 9.4.6
Vibration
IEC 61169-1, Subclause 9.3.3
Shock
IEC 61169-1, Subclause 9.3.14
Moisture resistance
IEC 61169-1, Subclause 9.4.3
Tooling
N/A
Suitable cables
N/A
Packing
Standard
1 pce in box
Weight
11.6 g/pce
Draft
Date
Approved
Date
Rev.
Engineering change number
Name
Date
Herbert Babinger
08/09/04
Armin Maiwaelder
04/01/06
b00
05-0717
Manuela Fuehrich
02/01/06
While the information has been carefully compiled to the best of our knowledge, nothing is intended as representation or warranty on
our part and no statement herein shall be construed as recommendation to infringe existing patents. In the effort to improve our
products, we reserve the right to make changes judged to be necessary.
