D a t a m a t e
Tooling
Standard circular crimp tool BS5210-3A-300 and MIL specification
M22520/2-01. Precision tool with ratchet mechanism and 8-indent
form. Must be used with positioner opposite. Instruction sheet
available.
Pneumatically operated crimp machine
Used with hand crimp tool shown opposite.
For inserting crimped socket contacts into the rear of mouldings.
Instruction sheet available.
HAND CRIMP TOOL
INSERTION/REMOVAL TOOL
POSITIONER
SEPARATOR TOOL
PNEUMATIC DATAMATE CRIMP MACHINE
Order Code
M22520/2-01
Order Code
T5748-19 (complete with tool bits)
Z80-250 (male crimp contacts only)
Order Code Crimp Machine
Z80-WA22AP
Order Code Positioner
Z80-KAP778-1
Order Code
T5747 (Small and Large bore crimp)
Order Code
Z80-058 (Power Crimp)
Order Code
T5746
G
Typical crimp rate is 600 per hour.
G
Meets the requirements of BS5210-3A-300 and
MIL M22520/2-01.
G
Instruction sheet available.
Recommended for unplugging latched connectors (tool releases the
latches prior to disengagement). Can also be used with unlatched
and friction lock connectors. Suitable for all sizes.
