www.tracopower.com
Page 2
All specifications valid at nominal input voltage, full load and +25°C after warm-up time unless otherwise stated.
Input Specifications
Input current
(no load)
TYL models
TVL models
< 95 mA
< 170 mA
Input current
(full load)
TYL models
TVL models
500 mA typ.
1’600 mA typ.
Otput Specifications
Voltage set accuracy
± 3 %
Regulation
– Input variation Vin min. to Vin max.
TYL models:
TVL models:
TYL models:
TVL models:
± 0.3 % max.
± 0.03 % max.
± 0.3 % max.
± 0.18 % max.
– Load variation 0 – 100 %
Ripple and noise
(20 MHz Bandwidth)
TYL models:
TVL models:
6 mVpk-pk max.
3 mVpk-pk max.
Temperature coefficient
± 0.02 % / °C
Output current limitation
>120 % of Iout max.
Short circuit protection
General Specifications
indefinite (automatic rcovery)
Temperature ranges
– Operating
– Storage
– 25°C ... +71°C
– 45°C ... +85°C
Derating
3%/°C above 50°C
Efficiency
60%
(TVL 05-05W 08: 45%)
Humidity
(non condensing)
30 – 95 % rel H max.
Reliability, calculated MTBF
(MIL-HDBK-217 F)
>1’000’000h @ + 25 °C
Isolation voltage
Input/ Output
500 VDC
Isolation capacity
Input/ Output
100 pF
Isolation resistance
Input/ Output (500 VDC)
> 10 M Ohm
Switching frequency
TYL models:
TVL models:
70 – 400 kHz depending on load
50 – 300 kHz depending on load
Vibration
5 to 10 Hz amplitude 10 mm pk-pk
10 to 55 Hz acceleration 2 G
Shock
acceleration 20 G max. time 11 ms
DC/DC Converter
TYL/TVL Series 1.5-5 Watt
