Functional Description
26
SLES140A—March 2007
TVP5147M1PFP
2.7.2 VBI Raw Data Output
The TVP5147M1 decoder can output raw A/D video data at twice the sampling rate for external VBI slicing.
This is transmitted as an ancillary data block, although somewhat differently from the way the sliced VBI data
is transmitted in the FIFO format as described in Section 2.7.1. The samples are transmitted during the active
portion of the line. VBI raw data uses ITU-R BT.656 format having only luma data. The chroma samples are
replaced by luma samples. The TVP5147M1 decoder inserts a four-byte preamble 000h 3FFh 3FFh 180h
before data start. There are no checksum bytes and fill bytes in this mode.
Table 28. VBI Raw Data Output Format
BYTE
NO.
D9
(MSB)
D8
D7
D6
D5
D4
D3
D2
D1
D0
(LSB)
DESCRIPTION
0
1
VBI raw data preamble
2
1
VBI raw data preamble
3
0
1
0
4
1. Data
5
2. Data
2 pixel rate luma data
:
2
× pixel rate luma data
(i.e., NTSC 601: n = 1707)
n1
n5. Data
(i.e., NTSC 601: n = 1707)
n
n–4. Data
2.8
Reset and Initialization
Reset is initiated at power up or any time terminal 34 (RESETB) is brought low. Table 29 describes the status
of the TVP5147M1 terminals during and immediately after reset.
Table 29. Reset Sequence
SIGNAL NAME
DURING RESET
RESET COMPLETED
Y[9:0], C[9:0]
Input
High-impedance
RESETB, PWDN, SDA, SCL, FSS,
AVID, GLCO, HS, VS, FID
Input
INTREQ
Input
Output
DATACLK
Output
High-impedance
200 ns (min)
RESETB
(Pin 34)
1 ms (min)
Invalid I2C Cycle
Valid
Normal Operation
Reset
1 ms (min)
SDA
(Pin 29)
POWER
(3.3 V and 1.8 V)
Figure 218. Reset Timing
The following register writes must be made before normal operation of the device.
STEP
I2C SUBADDRESS
I2C DATA
1
0x03
0x01
2
0x03
0x00
