SLVSAU9A
– MAY 2011 – REVISED AUGUST 2011
Register 0x04h Description: Ctrl
Table 24. TPS6236x Register 0x04h Description
REGISTER ADDRESS: 0x04h Read / Write
BIT
NAME
DEFAULT
DESCRIPTION
MSB
EN internal pull down resistor
D7
PD_EN
1
0 = disabled
1 = enabled
VSEL0 internal pull down resistor
D6
PD_VSEL0
1
0 = disabled
1 = enabled
VSEL1 internal pull down resistor
D5
PD_VSEL1
1
0 = disabled
1 = enabled
D4
x
Reserved for future use
D3
x
Reserved for future use
D2
x
Reserved for future use
D1
x
Reserved for future use
D0
LSB
x
Reserved for future use
Register 0x05h Description: Temp
Table 25. TPS6236x Register 0x05h Description
REGISTER ADDRESS: 0x05h Read/Write
BIT
NAME
DEFAULT
DESCRIPTION
D7
MSB
x
Reserved for future use
D6
x
Reserved for future use
D5
x
Reserved for future use
D4
x
Reserved for future use
D3
x
Reserved for future use
Disable temperature shutdown feature
D2
DIS_TS
0
0 = Temperature shutdown enabled
1 = Temperature shutdown disabled
TJ early warning bit
D1
TJEW
0
0 = TJ < 120°C (typ)
1 = TJ ≥ 120°C (typ)
TJ temperature shutdown bit
D0
TJTS
0
0 = die temperature within the valid range
1 = temperature shutdown was triggered
LSB
Bit needs to be reset after it has been latched.
Copyright
2011, Texas Instruments Incorporated
43
Product Folder Link(s): TPS62360 TPS62361B TPS62362
