TPS60240, TPS60241
TPS60242, TPS60243
SLVS372B
–
JUNE 2001
–
REVISED JANUARY 2002
4
www.ti.com
detailed description
operating principle
The TPS6024x charge pump is a fixed-frequency, dual-phase charge pump that provides 25 mA of continuous
supply current for low-noise applications such as VCOs used in cell phones and wireless appliances.
Low-noise operation results from using a proprietary dual-phase charge pump topology that relies on an
operational amplifier in the feedback loop to reduce ripple. During the first phase, C
1
is charged to the supply
voltage. Terminal C
1+
is connected to V
IN
, and C
1
–
is connected to GND. In the second phase, C
1
–
is connected
to the output of the operational amplifier, and C
1+
is connected to V
OUT
. The operational amplifier then adjusts
its output until the output V
OUT
delivers the correct voltage to make the resistor divided feedback point equal
to the reference voltage. During this second phase, C
2
is charged to supply voltage. Terminal C
2
–
is connected
to GND, and C
2+
is connected to V
IN
. Phase one is then repeated with C
2
, now acting to provide charge to the
output in place of C
1
, which is connected to the supply. The dual-phase operation lowers the output ripple
voltage significantly compared to a standard single-phase charge pump. In addition, the linear feedback of the
operational amplifier eliminates the ripple during discharge of the output capacitor (C
O
).
shutdown
Driving EN low disables the converter. This disables the internal circuits and reduces input current to typically
0.1
μ
A. In this mode, the load is disconnected from the supply voltage. The device exits shutdown once EN is
set to a high level.
start-up procedure
The converter is enabled when EN is set from logic low to high. The start-up time to reach 90% of the nominal
output voltage is typically 0.5 ms at load currents lower than 10 mA and with an output capacitor of 1
μ
F.
Increasing the values of C
O
delays the start-up time.
absolute maximum ratings over operating free-air temperature (unless otherwise noted)
Supply voltage, V
DD
Power dissipation, P
D
Voltage EN
Voltage C
2
–
, C
1
–
Voltage C
2+
, C
1+
Junction temperature, T
J
Storage temperature, T
stg
Shortcircuit output current
–
0.3 V to 6 V
Internally limited
–
0.3 V to 6 V
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
–
0.3 V to V
I
or 5.5 V, whichever is lowest
–
0.3 V to V
I
, V
O,
or 5.5 V, whichever is lowest
125
°
C
–
65
°
C to 150
°
C
80 mA maximum
Stresses beyond those listed under
“
absolute maximum ratings
”
may cause permanent damage to the device. These are stress ratings only, and
functional operation of the device at these or any other conditions beyond those indicated under
“
recommended operating conditions
”
is not
implied. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability.
DISSIPATION RATING TABLE
PACKAGE
TA
≤
25
°
C
POWER RATING
DERATING FACTOR
ABOVE TA = 25
°
C
3.76 mW/
°
C
TA = 70
°
C
POWER RATING
TA = 85
°
C
POWER RATING
DGK
376 mW
207 mW
150 mW
NOTE: The thermal resistance junction to ambient of the DGK package is RTH
–
JA = 150
°
C/W.
