| 型號： | TPD4104AKLBF |
| 元件分類： | 運動控制電子 |
| 英文描述： | BRUSHLESS DC MOTOR CONTROLLER, 3 A, PZFM23 |
| 封裝： | 1.27 MM PITCH, PLASTIC, HZIP-23 |
| 文件頁數： | 19/24頁 |
| 文件大小： | 340K |
| 代理商： | TPD4104AKLBF |
TPD4104AK
2005-01-31
4
Pin Description
Pin No.
Symbol
Pin Description
1
HU
The control terminal of IGBT by the side of U
top arm. It turns off more than by 1.5V.
It turns on more than by 3.5V.
2
HV
The control terminal of IGBT by the side of V
top arm. It turns off more than by 1.5V.
It turns on more than by 3.5V.
3
HW
The control terminal of IGBT by the side of W top arm. It turns off more than by 1.5V.
It turns on more than by 3.5V.
4
LU
The control terminal of IGBT by the side of U
bottom arm. It turns off more than by 1.5V.
It turns on more than by 3.5V.
5
LV
The control terminal of IGBT by the side of V
bottom arm. It turns off more than by 1.5V.
It turns on more than by 3.5V.
6
LW
The control terminal of IGBT by the side of W
bottom arm. It turns off more than by 1.5V.
It turns on more than by 3.5V.
7
IS1
IGBT emitter and FRD anode pin.
8
NC
Unused pin, which is not connected to the chip internally.
9
BSU
U-phase bootstrap capacitor connecting pin.
10
U
U-phase output pin.
11
VBB1
U and V-phase high-voltage power supply input pin.
12
BSV
V-phase bootstrap capacitor connecting pin.
13
V
V-phase output pin.
14
BSW
W-phase bootstrap capacitor connecting pin.
15
W
Ｗ-phase output pin.
16
VBB2
W-phase high-voltage power supply input pin.
17
NC
Unused pin, which is not connected to the chip internally.
18
IS2
IGBT emitter and FRD anode pin.
19
NC
Unused pin, which is not connected to the chip internally.
20
DIAG
With the diagnostic output terminal of open drain , a pull-up is carried out by resistance.
It turns it on at the time of unusual.
21
VCC
Control power supply pin.(15V typ.)
22
GND
Ground pin.
23
VREG
7V regulator output pin.
