www.ti.com
Trace Width
SLOS520 – AUGUST 2007
Recommended trace width at the solder balls is 75
μm to 100 μm to prevent solder wicking onto wider PCB
traces.
For high current pins (SW, PGND, VOUT+, VOUT–, VCCIN, and VCCOUT) of the TPA2013D1, use 100 μm trace
widths at the solder balls and at least 500
μm PCB traces to ensure proper performance and output power for
the device.
For low current pins (IN–, IN+, SDd, SDb, GAIN, VCCFB, VDD) of the TPA2013D1, use 75 μm to 100 μm trace
widths at the solder balls. Run IN- and IN+ traces side-by-side to maximize common-mode noise cancellation.
22
Copyright 2007, Texas Instruments Incorporated
Product Folder Link(s): TPA2013D1
