www.ti.com
AC OPERATING CHARACTERISTICS
TPA102
SLOS213D – AUGUST 1998 – REVISED SEPTEMBER 2004
V
DD = 5 V, TA = 25°C, RL = 8
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
PO
Output power (each channel)
THD
≤ 0.1%
70(1)
mW
THD+N
Total harmonic distortion + noise
PO = 150 mW, 20–20 kHz
2%
BOM
Maximum output power BW
G = 10, THD <5%
>20
kHz
Phase margin
Open loop
56
°
Supply ripple rejection ratio
f = 1 kHz
68
dB
Channel/Channel output separation
f = 1 kHz
86
dB
SNR
Signal-to-noise ratio
PO = 150 mW
100
dB
Vn
Noise output voltage
9.5
V(rms)
(1)
Measured at 1kHz
V
DD = 3.3 V, TA = 25°C, RL = 32
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
PO
Output power (each channel)
THD
≤ 0.1%
40(1)
mW
THD+N
Total harmonic distortion + noise
PO = 30 mW, 20–20 kHz
0.5%
BOM
Maximum output power BW
AV = 10, THD <2%
>20
kHz
Phase margin
Open loop
58
°
Supply ripple rejection ratio
f = 1 kHz
68
dB
Channel/channel output separation
f = 1 kHz
97
dB
SNR
Signal-to-noise ratio
PO = 100 mW
100
dB
Vn
Noise output voltage
9.5
V(rms)
(1)
Measured at 1kHz
V
DD = 5 V, TA = 25°C, RL = 32
PARAMETER
TEST CONDITIONS
MIN
TYP MAX
UNIT
PO
Output power (each channel)
THD
≤ 0.1%
40(1)
mW
THD+N
Total harmonic distortion + noise
PO = 60 mW, 20–20 kHz
0.4%
BOM
Maximum output power BW
AV = 10, THD <2%
>20
kHz
Phase margin
Open loop
56
°
Supply ripple rejection ratio
f = 1 kHz
68
dB
Channel/channel output separation
f = 1 kHz
97
dB
SNR
Signal-to-noise ratio
PO = 150 mW
100
dB
Vn
Noise output voltage
9.5
V(rms)
(1)
Measured at 1kHz
