參數資料
| 型號： | TK15412MTL |
| 廠商： | TOKO INC |
| 元件分類： | 消費家電 |
| 英文描述： | 75 OHM VIDEO LINE DRIVER |
| 中文描述： | SPECIALTY CONSUMER CIRCUIT, PDSO8 |
| 封裝： | SOT-23L, SMT-8 |
| 文件頁數： | 4/8頁 |
| 文件大?。?/td> | 64K |
| 代理商： | TK15412MTL |
Page 4
January 2000 TOKO, Inc.
TK15412
MEASUREMENT METHOD (CONT.)
6. Switch Threshold Voltage (High to Low) (V
)
The TP4 voltage is decreased very slowly. The TP4 voltage level is measured at the point where the TP1A signal is applied
to TP2 and the TP1B signal is stopped from TP2.
7. Switch Threshold Voltage (Low to High) (V
)
The TP4 voltage is increased very slowly. The TP4 voltage level is measured at the point where the TP1A signal is stopped
at TP2 and the TP1B signal is applied to TP2.
8. Clamp Voltage (V
)
The DC voltage at Pin 1 and Pin 3 is measured with no input signal.
9. Voltage Gain (GVA)
The voltage gain equation is as follows:
GVA = 20 log
V2/V1
Where V1 is the input voltage at TP1A and TP1B, and V2 is the measured voltage at TP2.
10. Differential Gain (DG)
The differential gain is measured at TP3 when a staircase waveform of 10 steps is applied to TP1A and TP1B.
11. Differential Phase (DP)
The differential phase is measured at TP3 when a staircase waveform of 10 steps is applied to TP1A and TP1B.
12. Frequency Response (fr)
The frequency response equation is as follows:
fr = 20 log
V2/V1
Where V1 is the measured TP3 voltage when the input frequency is set to 1 MHz and V2 is the measured TP3 voltage
when the input frequency is set to 5 MHz.
13. Cross Talk 1 (CT1)
The cross talk 1 equation is as follows:
CT1 = 20 log
V1/V2
When TP4 is connected to a High level, V1 is measured at TP2 when a 1 MHz 1 V
P-P
input signal is applied to TP1A. V2
is measured at TP2 when a 1 MHz 1 V
P-P
input signal is applied to TP1B.
14. Cross Talk 2 (CT2)
The cross talk 2 equation is as follows:
CT2 = 20 log
V1/V2
When TP4 is connected to a Low level, V1 is measured at TP2 when a 1 MHz 1 V
P-P
input signal is applied to TP1B. V2
is measured at TP2 when a 1 MHz 1 V
P-P
input signal is applied to TP1A.
