TFP501
PanelBus HDCP DIGITAL RECEIVER
SLDS127B JULY 2001 REVISED AUGUST 2002
7
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
electrical characteristics over recommended operating free-air temperature range (unless
otherwise noted)
dc digital I/O specifications
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
VIH
High level digital input voltage (CMOS Inputs)
(see Note 3)
0.7 VDD
V
VIL
Low level digital input voltage (CMOS Inputs)
(see Note 3)
0.3 VDD
V
VOH
High level digital output voltage (see Note 4)
DVDD = 3 V,
ST = High,
IOH = 5 mA
2.4
V
VOH
High level digital output voltage (see Note 4)
DVDD = 3 V,
ST = Low,
IOH = 3 mA
2.4
V
VOL
Low level digital output voltage (see Note 4)
DVDD = 3.6 V,
ST = High,
IOL = 10 mA
0.4
V
VOL
Low level digital output voltage (see Note 4)
DVDD = 3.6 V,
ST = Low
IOL = 5 mA
0.4
V
IOH(D)
High level output drive current (see Note 4)
ST = High,
VOH = 2.4V
5
12
18
mA
IOH(D)
High level output drive current (see Note 4)
ST = Low,
VOH = 2.4V
3
7
12
mA
IOL(D)
Low level output drive current (see Note 4)
ST = High,
VOL = 0.4V
10
13
19
mA
IOL(D)
Low level output drive current (see Note 4)
ST = Low,
VOL = 0.4V
5
7
11
mA
IIH
High level digital input current (see Note 3)
VIH = DVDD
±20
A
IIL
Low level digital input current (see Note 3)
VIL = 0.0
±60
A
IOZ
Hi-Z output leakage current
PD = Low or PDO = Low
±20
A
NOTES:
3. Digital inputs are labeled I in I/O column of Terminal Functions Table.
4. Digital outputs are labeled O in I/O column of Terminal Functions Table.
dc specifications
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
VID(1)
Analog input differential voltage (see Note 5)
150
1200
mV
VIC
Analog input common mode voltage (see Note 5)
AVDD0.3
AVDD0.037
V
VI(OC)
Open circuit analog input voltage
AVDD0.01
AVDD+0.01
V
IDD(2PIX) Normal 2-pix/clock power supply current (see Note 7)
ODCK = 82.5 MHz
2-pix/clock
460
mA
I(PD)
Power down current (see Note 6)
PD = Low
10
mA
I(PDO)
Output drive power down current (see Note 6)
PDO = Low
35
mA
NOTES:
5. Specified as dc characteristic with no overshoot or undershoot.
6. Analog inputs are open circuit (transmitter is disconnected from TFP501.)
7. Alternating 2-pixel black/2-pixel white pattern. ST = high, STAG = high, QE{23:0] and Q0[23:0] CL = 10 pF.
