TFP401, TFP401A
TI
PanelBus DIGITAL RECEIVER
SLDS120C - MARCH 2000 REVISED MAY 2011
7
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
electrical characteristics over recommended operating free-air temperature range (unless
otherwise noted) (continued)
ac specifications
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
UNIT
VID(2)
Differential input sensitivity
150
1560
mVp-p
tps
Analog input intra-pair (+ to -) differen-
tial skew (see Note 6)
0.4
tbit
tccs
Analog Input inter-pair or channel-to-
channel skew (see Note 6)
1
tpix§
tijit
Worse case differential input clock jitter
tolerance (see Note 6)
50
ps
tf1
Fall time of data and control signals#, ||
ST = Low,
CL=5 pF
ST = High,
CL=10 pF
2.4
1.9
ns
tr1
Rise time of data and control signals#, ||
ST = Low,
CL=5 pF
ST = High,
CL=10 pF
2.4
1.9
ns
tr2
Rise time of ODCK clock#
ST = Low,
CL=5 pF
ST = High,
CL=10 pF
2.4
1.9
ns
tf2
Fall time of ODCK clock#
ST = Low,
CL=5 pF
ST = High,
CL=10 pF
2.4
1.9
ns
1 pixel/clock, PIXS = low, OCK_INV = low
1.8
tsu1
Setup time, data and control signal to
falling edge of ODCK
2 pixel/clock, PIXS = high, STAG/ = high,
OCK_INV = low
3.8
ns
tsu1
falling edge of ODCK
2 pixel and STAG, PIXS = high,
STAG/ = low, OCK_INV = low
0.7
ns
1 pixel/clock, PIXS = low, OCK_INV = low
0.6
th1
Hold time, data and control signal to
falling edge of ODCK
2 pixel and STAG, PIXS = high,
STAG/ = low, OCK_INV = low
2.5
ns
th1
falling edge of ODCK
2 pixel/clock, PIXS = high,
STAG/ = high, OCK_INV = low
2.9
ns
1 pixel/clock, PIXS = low, OCK_INV = high
2.1
tsu2
Setup time, data and control signal to
rising edge of ODCK
2 pixel/clock, PIXS = high,
STAG/ = high, OCK_INV = high
4
ns
tsu2
rising edge of ODCK
2 pixel and STAG, PIXS = high,
STAG/ = low, OCK_INV = high
1.5
ns
1 pixel/clock, PIXS = low, OCK_INV = high
0.5
th2
Hold time, data and control signal to
rising edge of ODCK
2 pixel and STAG, PIXS = high,
STAG/ = low, OCK_INV = high
2.4
ns
th2
rising edge of ODCK
2 pixel/clock, PIXS = high,
STAG/ = high, OCK_INV = high
2.1
ns
f
ODCK frequency
PIX = Low (1-PIX/CLK)
25
165
MHz
fODCK
ODCK frequency
PIX = High (2-PIX/CLK)
12.5
82.5
MHz
ODCK duty-cycle
45%
60%
75%
Specified as ac parameter to include sensitivity to overshoot, undershoot and reflection.
tbit is 1/10 the pixel time, tpix
§ tpix is the pixel time defined as the period of the RxC input clock. The period of ODCK is equal to tpix in 1-pixel/clock mode or 2tpix when in
2-pixel/clock mode.
Measured differentially at 50% crossing using ODCK output clock as trigger.
# Rise and fall times measured as time between 20% and 80% of signal amplitude.
|| Data and control signals are : QE[23:0], QO[23:0], DE, HSYNC, VSYNC and CTL[3:1]
kLink active or inactive is determined by amount of time detected between DE transitions. SCDT indicates link activity.
NOTE 6: By characterization
