TFDU6102E/TFDS6502E/TFDT6502E
Vishay Telefunken
TFDU6101E/TFDS6501E/TFDT6501E
Rev. B1.2, 07.04.99
11
www.vishay.de
FaxBack +1-408-970-5600
Document Number 82519
1.27
0.8
18
8.89
1.8
15068
Figure 9. TFDT6501E/ TFDT6502E Top View Package
Pad 1 is longer to designate Pin 1 connection to transceiver.
Note: Leads of the device should be at least 0.3 mm within the ends of the pads.
Recommended Solder Profile
Time ( s )
T
emperature
(
C
)
14874
°
0
30
60
90
120
150
180
210
240
0
50
100
150
200
250
300
350
2 - 4
°C/s
10 s max.
@ 230
°C
90 s max.
120 - 180 s
2 - 4
°C/s
Figure 10. Recommended Solder Profile
Current Derating Diagram
0
100
200
300
400
500
600
–40 –20
0
20
40
60
80 100 120 140
Peak
Operating
Current
(
mA
)
Temperature (
°C )
14875
Current derating as a function of the
maximum forward current of IRED.
Maximum duty cycle: 25%.
Figure 11. Current Derating Diagram
