ELECTRICAL CHARACTERISTICS
(refer to the test circuit ; VS =
± 12V, Tamb = 25oC unless otherwise specified)
Symbol
Parameter
Test Conditions
Min.
Typ.
Max.
Unit
Vs
Supply Voltage
± 6
± 15
V
Id
Quiescent Drain Current
Vs =
± 15V
40
80
mA
Ib
Input Bias Current
Vs =
± 15V
0.2
3
A
VOS
Input Offset Voltage
Vs =
± 15V
± 8mV
IOS
Input Offset Current
V=
± 15V
± 80
nA
VOS
Output Offset Voltage
Vs =
± 15V
± 10 ± 100 mV
Po
Output Power
d = 10%, f = 1kHz
RL = 4
RL = 8
6
12
8
W
d
Distortion
Po = 0.1 to 8W, RL = 4
, f = 1kHz
Po = 0.1 to 4W, RL = 8
, f = 1kHz
0.2
0.1
%
Vi
Input Sensitivity
Po = 10W, RL = 4
, f = 1kHz
Po = 6W, RL = 8
, f = 1kHz
200
220
mV
B
Frequency Response (– 3dB)
Po = 8W, RL = 4
20Hz to 100kHz
Ri
Input Resistance (pin 1)
f = 1kHz
0.5
5
M
Gv
Voltage Gain (open loop)
f = 1kHz
75
dB
Gv
Voltage Gain (closed loop)
f = 1kHz
29.5
30
30.5
dB
eN
Input Noise Voltage
B (– 3dB) = 22Hz to 22kHz, RL = 4
310
V
iN
Input Noise Current
B (– 3dB) = 22Hz to 22kHz, RL = 4
80
200
pA
SVR
Supply Voltage Rejection
RL = 4
, Rg = 22k, fripple = 100Hz (*)
40
50
dB
Id
Drain Current
Po = 12W, RL = 4
Po = 8W, RL = 8
850
500
mA
Tj
Thermal Shutdown Junction
Temperature
145
°C
(*) Referring to Figure 15, single supply.
