Precision Edge SY89830U Micrel, Inc. M9999-110705 hbwhelp@micrel.com or (408) 955-1690
參數資料
型號： SY89830UK4I
廠商： Micrel Inc
文件頁數： 5/10頁
文件大?。?/td> 0K
描述： IC CLOCK BUFFER MUX 2:4 16-TSSOP
標準包裝： 94
系列： Precision Edge®
類型： 扇出緩沖器（分配），多路復用器
電路數： 1
比率 - 輸入:輸出： 2:4
差分 - 輸入:輸出： 是/是
輸入： HSTL，LVECL，LVPECL
輸出： LVECL，LVPECL
頻率 - 最大： 2.5GHz
電源電壓： 2.375 V ~ 5.5 V
工作溫度： -40°C ~ 85°C
安裝類型： 表面貼裝
封裝/外殼： 16-TSSOP（0.173"，4.40mm 寬）
供應商設備封裝： 16-TSSOP
包裝： 管件
4
Precision Edge
SY89830U
Micrel, Inc.
M9999-110705
hbwhelp@micrel.com or (408) 955-1690
TA = –40°CTA = +25°CTA = +85°C
Symbol
Parameter
Min.
Typ.
Max.
Min.
Typ.
Max.
Min.
Typ.
Max.
Unit
Condition
V
IL
Input LOW Voltage
555
—
875
555
—
875
555
—
875
mV
VCC = 2.5V
(Single-ended)
V
IH
Input HIGH Voltage
1275
—
1620
1275
—
1620
1275
—
1620
mV
VCC = 2.5V
(Single-ended)
V
OL
Output LOW Voltage
555
680
805
555
680
805
555
680
805
mV
VCC = 2.5V
V
OH
Output HIGH Voltage
1355
1480
1605
1355
1480
1605
1355
1480
1605
mV
VCC = 2.5V
V
IHCMR
Input HIGH Voltage
1.2
—
VCC
1.2
—
VCC
1.2
—
VCC
V
Common Mode Range(2)
(100KEP) LVPECL DC ELECTRICAL CHARACTERISTICS(1)
VCC = 2.5V ±5%, VEE = 0V
Notes:
1. 100KEP circuits are designed to meet the DC specifications shown in the above table after thermal equilibrium has been established. The circuit is in a
test socket or mounted on a printed circuit board and traverse airflow greater than 500lfpm is maintained. Input and output parameters vary 1:1 with V
CC.
Output load is 50
to V
CC –2V.
2. The V
IHCMR range is referenced to the most positive side of the differential input signal.
TA = –40°CTA = +25°CTA = +85°C
Symbol
Parameter
Min.
Typ.
Max.
Min.
Typ.
Max.
Min.
Typ.
Max.
Unit
Condition
V
IL
Input LOW Voltage
1355
—
1675
1355
—
1675
1355
—
1675
mV
VCC = 3.3V
(Single-Ended)
V
IH
Input HIGH Voltage
2075
—
2420
2075
—
2420
2075
—
2420
mV
VCC = 3.3V
(Single-Ended)
V
OL
Output LOW Voltage
1355
1480
1605
1355
1480
1605
1355
1480
1605
mV
VCC = 3.3V
V
OH
Output HIGH Voltage
2155
2280
2405
2155
2280
2405
2155
2280
2405
mV
VCC = 3.3V
V
IHCMR
Input HIGH Voltage
1.2
—
VCC
1.2
—
VCC
1.2
—
VCC
V
Common Mode Range(2)
(100KEP) LVPECL DC ELECTRICAL CHARACTERISTICS(1)
V
CC = 3.3V ±10%, VEE = 0V
Notes:
1. 100KEP circuits are designed to meet the DC specifications shown in the above table after thermal equilibrium has been established. The circuit is in a
test socket or mounted on a printed circuit board and traverse airflow greater than 500lfpm is maintained. Input and output parameters vary 1:1 with V
CC.
Output load is 50
to V
CC –2V.
2. The V
IHCMR range is referenced to the most positive side of the differential input signal.
TA = –40°CTA = +25°CTA = +85°C
Symbol
Parameter
Min.
Typ.
Max.
Min.
Typ.
Max.
Min.
Typ.
Max.
Unit
Condition
V
IL
Input LOW Voltage
3055
—
3375
3055
—
3375
3055
—
3375
mV
VCC = 5.0V
(Single-Ended)
V
IH
Input HIGH Voltage
3775
—
4120
3775
—
4120
3775
—
4120
mV
VCC = 5.0V
(Single-Ended)
V
OL
Output LOW Voltage
3055
3180
3305
3055
3180
3305
3055
3180
3305
mV
VCC = 5.0V
V
OH
Output HIGH Voltage
3855
3980
4105
3855
3980
4105
3855
3980
4105
mV
VCC = 5.0V
V
IHCMR
Input HIGH Voltage(2)
1.2
—
V
CC
1.2
—
V
CC
1.2
—
V
CC
V
Common Mode Range
(100KEP) PECL DC ELECTRICAL CHARACTERISTICS(1)
VCC = 5.0V ±10%, VEE = 0V
Notes:
1. 100KEP circuits are designed to meet the DC specifications shown in the above table after thermal equilibrium has been established. The circuit is in a
test socket or mounted on a printed circuit board and traverse airflow greater than 500lfpm is maintained. Input and output parameters vary 1:1 with V
CC.
Output load is 50
to V
CC –2V.
2. The V
IHCMR range is referenced to the most positive side of the differential input signal.
