SP-03-xxx-xNFM
DS-5749 Rev 02 2010-05-06
Units in mm(inch)
Figure 4, Mechanical Design Diagram of the SFP
Order Information
Table 9–
Order Information
Part No.
Application
Temperature
Data Rate
Laser Source
Fiber Type
SP-03-IR1-CNFM
SDH STM-1, S-1.1
SONET OC-3 IR1
-5~+70°C
155Mbps
1310nm FP
SMF
SP-03-IR1-INFM
SDH STM-1, S-1.1
SONET OC-3 IR1
-40~+85°C
155Mbps
1310nm FP
SMF
SP-03-LR1-CNFM
SDH STM-1, L-1.1
SONET OC-3 LR1
-5~+70°C
155Mbps
1310nm FP
SMF
SP-03-LR1-INFM
SDH STM-1, L-1.1
SONET OC-3 LR1
-40~+85°C
155Mbps
1310nm FP
SMF
Warnings
Handling Precautions:
This device is susceptible to damage as a result of electrostatic discharge (ESD). A static
free environment is highly recommended. Follow guidelines according to proper ESD procedures.
