參數資料
型號： SN74ABT5402DW
廠商： TEXAS INSTRUMENTS INC
元件分類： 總線收發器
英文描述： ABT SERIES, 12-BIT DRIVER, TRUE OUTPUT, PDSO28
文件頁數： 5/11頁
文件大?。?/td> 246K
代理商： SN74ABT5402DW
SN54ABT5402, SN74ABT5402
12BIT LINE/MEMORY DRIVERS
WITH 3STATE OUTPUTS
SCBS100B JANUARY 1992 REVISED JULY 1994
63
POST OFFICE BOX 655303
DALLAS, TEXAS 75265
POST OFFICE BOX 1443
HOUSTON, TEXAS 772511443
recommended operating conditions (see Note 3)
SN54ABT5402
SN74ABT5402
UNIT
MIN
MAX
MIN
MAX
UNIT
VCC
Supply voltage
4.5
5.5
4.5
5.5
V
VIH
High-level input voltage
2
V
VIL
Low-level input voltage
0.8
V
VI
Input voltage
0
VCC
0
VCC
V
IOH
High-level output current
12
mA
IOL
Low-level output current
12
mA
t/v
Input transition rise or fall rate
Outputs enabled
10
ns / V
TA
Operating free-air temperature
55
125
40
85
°C
NOTE 3: Unused or floating inputs must be held high or low.
electrical characteristics over recommended operating free-air temperature range (unless
otherwise noted)
PARAMETER
TEST CONDITIONS
TA = 25°C
SN54ABT5402
SN74ABT5402
UNIT
PARAMETER
TEST CONDITIONS
MIN
TYP
MAX
MIN
MAX
MIN
MAX
UNIT
VIK
VCC = 4.5 V,
II = 18 mA
1.2
V
VCC = 4.5 V,
IOH = 1 mA
3.35
3.7
3.3
3.35
VOH
VCC = 5 V,
IOH = 1 mA
3.85
4.2
3.8
3.85
V
VOH
VCC = 4.5 V
IOH = 3 mA
3
3.1
V
VCC = 4.5 V
IOH = 12 mA
2.6
VOL
VCC = 4.5 V
IOL = 8 mA
0.8
0.65
V
VOL
VCC = 4.5 V
IOL = 12 mA
0.8
V
II
VCC = 5.5 V,
VI = VCC or GND
±1
A
IOZH
VCC = 5.5 V,
VO = 2.7 V
50
A
IOZL
VCC = 5.5 V,
VO = 0.5 V
50
A
Ioff
VCC = 0,
VI or VO ≤ 4.5 V
±100
A
ICEX
VCC = 5.5 V,
VO = 5.5 V
Outputs high
50
A
IO
VCC = 5.5 V,
VO = 2.5 V
25
45
100
25
100
25
100
mA
IOS
VCC = 5.5 V,
VO = 0
50
200
50
200
50
200
mA
VCC = 5.5 V,
IO = 0,
Outputs high
5
50
A
ICC
VCC = 5.5 V,
IO = 0,
VI = VCC or GND
Outputs low
36
45
mA
VI = VCC or GND
Outputs disabled
1
50
A
VCC = 5.5 V,
One input at
Data inputs
Outputs enabled
1.5
ICC§
One input at
3.4 V, Other
inputs at
Data inputs
Outputs disabled
0.05
mA
inputs at
VCC or GND
Control inputs
1.5
Ci
VI = 2.5 V or 0.5 V
3
pF
Co
VO = 2.5 V or 0.5 V
8
pF
All typical values are at VCC = 5 V.
Not more than one output should be tested at a time, and the duration of the test should not exceed one second.
§ This is the increase in supply current for each input that is at the specified TTL voltage level rather than VCC or GND.
PRODUCT PREVIEW information concerns products in the formative or
design phase of development. Characteristic data and other
specifications are design goals. Texas Instruments reserves the right to
change or discontinue these products without notice.
