XE162FM, XE162HM
XE166 Family Derivatives / Base Line
Electrical Parameters
Data Sheet
68
V2.0, 2009-03
4.2.3
Power Consumption
The power consumed by the XE162xM depends on several factors such as supply
voltage, operating frequency, active circuits, and operating temperature. The power
consumption specified here consists of two components:
The switching current
I
S depends on the device activity
The leakage current
I
LK depends on the device temperature
To determine the actual power consumption, always both components, switching current
I
S (Table 15) and leakage current ILK (Table 16) must be added:
I
DDP = IS + ILK.
Note: The power consumption values are not subject to production test. They are
verified by design/characterization.
To determine the total power consumption for dimensioning the external power
supply, also the pad driver currents must be considered.
The given power consumption parameters and their values refer to specific operating
conditions:
Active mode:
Regular operation, i.e. peripherals are active, code execution out of Flash.
Stopover mode:
Crystal oscillator and PLL stopped, Flash switched off, clock in domain DMP_1
stopped.
Note: The maximum values cover the complete specified operating range of all
manufactured devices.
The typical values refer to average devices under typical conditions, such as
nominal supply voltage, room temperature, application-oriented activity.
After a power reset, the decoupling capacitors for
V
DDI are charged with the
maximum possible current.
For additional information, please refer to Section 5.2, Thermal Considerations.
Note: Operating Conditions apply.
Table 15
Switching Power Consumption XE162xM
Parameter
Sym-
bol
Values
Unit Note /
Test Condition
Min. Typ.
Max.
Power supply current
(active) with all peripherals
active and EVVRs on
I
SACT
–
10 +
0.6
×f
SYS
10 +
1.0
×f
SYS
mA
Active mode1)2)3)
f
SYS in [MHz]
Power supply current
in stopover mode,
EVVRs on
I
SSO
–
0.7
2.0
mA
Stopover Mode3)
