參數資料
| 型號： | SAB-C165-L25F |
| 廠商： | SIEMENS A G |
| 元件分類： | 微控制器/微處理器 |
| 英文描述： | 16-BIT, 14 MHz, MICROCONTROLLER, PQFP100 |
| 封裝： | TQFP-100 |
| 文件頁數： | 16/18頁 |
| 文件大?。?/td> | 306K |
| 代理商： | SAB-C165-L25F |
11Jul97@13:32h Intermediate Version
5
Semiconductor Group
C165 / 3 V
Absolute Maximum Ratings
Ambient temperature under bias (
TA):
SAB-C165-L25M, SAB-C165-R25M, SAB-C165-L25F, SAB-C165-R25F....................... 0 to +70 °C
SAF-C165-L25M ........................................................................................................... -40 to +85 °C
Storage temperature (
TST)......................................................................................... – 65 to +150 °C
Voltage on
V
CC pins with respect to ground (VSS) ....................................................... –0.5 to +6.5 V
Voltage on any pin with respect to ground (
V
SS) ................................................... –0.5 to VCC +0.5 V
Input current on any pin during overload condition .................................................... –10 to +10 mA
Absolute sum of all input currents during overload condition ..............................................|100 mA|
Power dissipation..................................................................................................................... 1.5 W
Note: Stresses above those listed under “Absolute Maximum Ratings” may cause permanent
damage to the device. This is a stress rating only and functional operation of the device at
these or any other conditions above those indicated in the operational sections of this
specification is not implied. Exposure to absolute maximum rating conditions for extended
periods may affect device reliability. During overload conditions (
V
IN>VCC or VIN<VSS) the
voltage on pins with respect to ground (
VSS) must not exceed the values defined by the
Absolute Maximum Ratings.
Parameter Interpretation
The parameters listed in the following partly represent the characteristics of the C165 and partly its
demands on the system. To aid in interpreting the parameters right, when evaluating them for a
design, they are marked in column “Symbol”:
CC (Controller Characteristics):
The logic of the C165 will provide signals with the respective timing characteristics.
SR (System Requirement):
The external system must provide signals with the respective timing characteristics to the C165.
DC Characteristics
VCC = 2.7 V to 3.6 V; VSS = 0 V
T
A = 0 to +70 °C
for SAB-C165-L25M, SAB-C165-R25M, SAB-C165-L25F, SAB-C165-R25F
T
A = -40 to +85 °C
for SAF-C165-L25M
Parameter
Symbol
Limit Values
Unit
Test Condition
min.
max.
Input low voltage
V
IL
SR – 0.5
0.8
V
–
Input high voltage
(all except RSTIN and XTAL1)
VIH
SR 2.0
VCC + 0.5
V
–
Input high voltage RSTIN
VIH1 SR 0.6 VCC
VCC + 0.5
V
–
Input high voltage XTAL1
V
IH2
SR 0.7
V
CC
V
CC + 0.5
V
–
