Input:
Input:
Output:
Current:
PPackage:
ackage:
35-75 V
48 V
3 A
3 A (144W)
(144W)
Quarter-brick
T
Technical S
echnical Specification
pecification
Product # PQ60480QTA03
Phone 1-888-567-9596
Doc.# 005-2QT648C Rev. A
9/4/07
Page 3
Parameter
Min.
Typ.
Max.
Units
Notes & Conditions
ABSOLUTE MAXIMUM RATINGS
Input Voltage
Non-Operating
100
V
Continuous
Operating
80
V
Continuous
Operating Transient Protection
100
V
100ms transient, square wave
Isolation Voltage (input to output)
2000
V
Basic insulation, Pollution Degree 2
Operating Temperature
-40
100
°C
Storage Temperature
-55
125
°C
Voltage at ON/OFF input pin
-2
18
V
INPUT CHARACTERISTICS
Operating Input Voltage Range
35
48
75
V
100V transient for 100ms
Input Under-Voltage Lockout
Turn-On Voltage Threshold
31.5
32.5
34.0
V
Turn-Off Voltage Threshold
28.7
29.5
31.2
V
Lockout Voltage Hysteresis
2.5
3.5
4.5
V
Maximum Input Current
5.1
A
100% Load, 35 Vin, trimmed up 5%
No-Load Input Current
120
150
mA
Disabled Input Current
2
5mA
Inrush Current Transient Rating
0.01
A2s
Response to Input Transient
1
V
1000V/ms input transient
Input Reflected Ripple Current
13
mA
P-P thru 10H inductor; Figures
13 &
15Input Terminal Ripple Current
40
mA
Recommended Input Fuse
20
A
Fast blow external fuse recommended
Input Filter Component Values (L\C)
3.3\6.6
H\F
Internal values; Figure
E (Lin\C2)
Recommended External Input Capacitance
47
F
Typical ESR 0.1-0.2W; Figure
13OUTPUT CHARACTERISTICS
Output Voltage Set Point
47.4
48.00
48.6
V
Output Voltage Regulation
Over Line1
+0.02\10
+0.1\48
%\mV
Over Load1
+0.02\10
+0.1\48
%\mV
Over Temperature
+288
+400
mV
Total Output Voltage Range
46.9
49.1
V
Over sample, line, load, temperature & life
Output Voltage Ripple and Noise2
500MHz bandwidth; Figures
13 &
16Peak-to-Peak
12
150
mV
Full Load; Figures
13 &
16RMS
5
60
mV
Full Load; Figures
13 &
16Operating Output Current Range
0
3
A
Subject to thermal derating; Figures
5 - 8Output DC Current-Limit Inception
3.5
3.8
4.4
A
Output Voltage 10% Low
Output DC Current-Limit Shutdown Voltage
19
V
Back-Drive Current Limit while Enabled
0.1
0.3
0.8
A
Negative current drawn from output source
Back-Drive Current Limit while Disabled
0
30
55
mA
Negative current drawn from output source
Maximum Output Capacitance
688
F
48Vout at 3A Resistive Load
DYNAMIC CHARACTERISTICS
Input Voltage Ripple Rejection
20
dB
Output Voltage during Load Current Transient
For a Step Change in Output Current (0.1A/s)
2
V
50% to 75% to 50% Iout max
Settling Time
500
s
To within 1% Vout nom
Turn-On Transient
Turn-On Time
33
ms
Full load, ON/OFF to Vout=90% nom.; Figures
9 - 10Start-Up Inhibit Time
230
250
270
ms
-40°C to +125°C; Figure
EOutput Voltage Overshoot
0
%
688 F load capacitance, Iout = 0A
EFFICIENCY
100% Load
92
%
50% Load
92
%
TEMPERATURE LIMITS FOR POWER DERATING CURVES
Semiconductor Junction Temperature
125
°C
Package rated to 150°C
Board Temperature
125
°C
UL rated max operating temp 130°C
Transformer Temperature
125
°C
See Figures
5 - 8 for derating curves
ISOLATION CHARACTERISTICS
Isolation Voltage (dielectric strength)
2000
V
Isolation Resistance
30
MW
Isolation Capacitance3
470
pF
PQ60480QTA03 ELECTRICAL CHARACTERISTICS
TA=25°C, airflow rate=300 LFM, Vin=48Vdc unless otherwise noted; full operating temperature range is -40°C to +100°C ambient tem-
perature with appropriate power derating. Specifications subject to change without notice.
Note 1: Line and load regulation is limited by duty cycle quantization and does not indicate a shift in the internal voltage reference.
Note 2: For applications requiring reduced output voltage ripple and noise, consult SynQor applications support (e-mail:
support@synqor.com).Note 3: Higher values of isolation capacitance can be added external to the module.
