1996 Dec 18
24
Philips Semiconductors
Product specification
8-bit microcontroller with DTMF generator,
256 bytes EEPROM and real-time clock
PCD3350A
14 SUMMARY OF I/O PORTS AND ROM MASK OPTIONS
All standard quasi-bidirectional I/O ports are available; see “PCD33xxA Family”data sheet.
Port 0: 8 parallel port lines P0.0 to P0.7
Port 1: 8 parallel port lines P1.0 to P1.7
Port 2: 4 parallel port lines P2.0 to P2.3.
In addition to the standard ports, two derivative I/O ports are available:
Derivative Port 0: 6 parallel port lines DP0.0 to DP0.5 (register DP0L)
Derivative Port 1: 8 parallel port lines DP1.0 to DP1.7 (register DP1L).
The port options and the other ROM mask options are listed in Table 27. See Table 28 for the addresses of DP0L and
DP1L.
Table 27
ROM mask options
Notes
1.
If standard (Option 1) or push-pull (Option 3) output is chosen, the P1.7/MDY output becomes a push-pull output.
If open-drain (Option 2) is chosen, the P1.7/MDY output becomes an open-drain output.
If standard (Option 1) or push-pull (Option 3) output is chosen, the DP1.7/DCO output becomes a push-pull output.
If open-drain (Option 2) is chosen, the DP1.7/DCO output becomes an open-drain output.
2.
FUNCTION IMPLEMENTED IN ROM
OPTION
Program/data
Any mix of instructions and data up to ROM size of
8 kbytes.
Port Output
P0.0 to P0.7
P1.0 to P1.6
P1.7/MDY; note 1
P2.0 to P2.3
DP0.0 to DP0.5
DP1.0 to DP1.6
DP1.7/DCO; note 2
standard
standard
standard
standard
standard
standard
standard
open-drain
open-drain
open-drain
open-drain
open-drain
open-drain
open-drain
push-pull
push-pull
push-pull
push-pull
push-pull
push-pull
push-pull
Port State after reset
P0.0 to P0.7
P1.0 to P1.6
P1.7/MDY
P2.0 to P2.3
DP0.0 to DP0.5
DP1.0 to DP1.6
DP1.7/DCO
set
set
set
set
set
set
set
reset
reset
reset
reset
reset
reset
reset
Oscillator
Transconductance
LOW (g
mL
)
MEDIUM (g
mM
)
HIGH (g
mH
)
Power-on-reset
Power-on-reset voltage level: V
POR
1.2 to 3.6 V in increments of 100 mV; OFF
