Features
Small size, light weight.
Low coil consumption.
PC board mounting.
Suitable for household electrical appliance, automation system, electronic equipment, instrument, meter,
telecommunication facilities and remote control facilities.
Ordering Information
NT78 C S 10 DC12V 0.6
1 2 3 4 5 6
1 Part number
：
NT78
2 Contact arrangement
：
A:1A
；
B:1B
；
C:1C
；
U:1U
3 Enclosure
：
S: Sealed type
；
NIL: Dust cover
4 Contact rating
：
5A,10A/14VDC
；
10A/120VAC
；
5A/250VAC
5 Coil rated Voltage(V)
：
DC:6,9,12,24
6 Coil power consumption
：
0.6:0.6W
；
0.8:0.8W
Contact Data
Contact Arrangement
Contact Material
Contact Rating (resistive)
1A
Ag CdO Ag SnO
Ag SnO
I
n
O
NO:20A/14VDC 10A/120VAC,5A/250VAC
NC:15A/14VDC,10A/120VAC,5A/250VAC
Motor load : 1/2HP 125VAC
Lamp load : TV-5
280W 1250VA
42VDC 380VAC Max. Switching Current:20A
50m
Item 3.12 of IEC255-7
10
5
Item 3.30 of IEC255-7
10
7
Item 3.31 of IEC255-7
SPSTNO
1B
SPSTNC
1C
SPDT(B-M)
1U
SPSTNODM
IU:2
10A/14VDC
Max. Switching Power
Max. Switching Voltage
Contact Resistance or Voltage drop
Electrical
Operation
life
Mechanical
Coil Parameter
Coil voltage
VDC
Dash
numbers
Rated
Max.
Coil
resistance
±
10%
Pickup
voltage
VDC(max)
(80%of rated
voltage )
release voltage
VDC(min)
(5% of rated
voltage)
Coil power
consumption
W
Operate
Time
ms
Release
Time
ms
006-600
009-600
012-600
024-600
6
9
12
24
6.6
9.9
13.2
26.4
60
135
240
960
4.8
7.2
9.6
19.2
0.30
0.45
0.60
1.20
0.6
10
5
006-800
009-800
012-800
024-800
6
9
12
24
6.6
9.9
13.2
26.4
45
102
180
720
4.8
7.2
9.6
19.2
0.30
0.45
0.60
1.20
0.8
10
5
CAUTION
:
1.The use of any coil voltage less than the rated coil voltage will compromise the operation of the relay.
2.Pickup and release voltage are for test purposes only and are not to be used as design criteria.
91
on Pending
Patent No. 99206529.1
