| 型號： | MSR320R |
| 廠商： | Mallory Sonalert Products Inc |
| 文件頁數： | 2/2頁 |
| 文件大?。?/td> | 0K |
| 描述： | AUD SIG DEVICE 3-20VDC PCB |
| 音頻文件： | 3400 Hz Continuous |
| 產品目錄繪圖： | Buzzer Side |
| 3D 型號： | MSR.igs MSR.stp MSR.sat |
| 標準包裝： | 1 |
| 系列： | Sonalert® |
| 驅動器電路： | 指示燈，內部驅動 |
| 技術： | 壓電 |
| 輸入類型： | DC |
| 電壓范圍： | 3 ~ 20V |
| 頻率： | 3.5kHz |
| 工作模式： | 連續 |
| 聲壓級： | 71dB @ 3V，61cm |
| 電流 - 電源： | 3 ~ 16mA |
| 可清洗： | 無 |
| 安裝類型： | 通孔 |
| 端子： | PC 引腳 |
| 尺寸/尺寸： | 圓形 - 23.00mm 直徑 x 10.10mm H |
| 包裝： | 散裝 |
| 工作溫度： | -40°C ~ 85°C |
| 產品目錄頁面： | 2657 (CN2011-ZH PDF) |
| 其它名稱： | 458-1087 |
MSR & MSO Series Buzzers
Aqueous Wash:
In order to process MSR & MSO Series buzzers through an aqueous wash, the
buzzer must have a wash label and be sealed on the back with epoxy. Sealed
buzzers have a “SR” suffix in the part number. For example, P/N MSR320SR is
sealed and appropriate for aqueous wash. P/N MSR320R is not sealed.
After aqueous wash, the wash label must be removed from the buzzer.
Wave Solder Profile:
Refer to the wave solder machine manufacturer’s recommended wave solder
profile. If needed, adjust the maximum time & temperature to 270°C for 3
seconds to process MSR & MSO series buzzers.
Moisture Sensitivity Level (MSL): Level 1 (Unlimited)
Packaging: All parts are bulk packed.
Origin: Made in USA
Sound Level vs Distance:
Sound level decreases as the sound waves travel over distance, so it is important
to note the specified distance when comparing sound levels. For example, if a
buzzer measures 88 decibels (dB) at 30 cm, then it will measure:
97 dB @ 10 cm
82 dB @ 60 cm
78 dB @ 1 Meter
Mallory Sonalert has developed a tool to help convert sound levels depending on
the distance. You can download the tool from our website: http://www.mallory-
