AC Electrical Characteristics
*
T
A
e
25
§
C, C
L
e
50 pF, unless otherwise specified
Symbol
Parameter
Conditions
Min
Typ
Max
Units
t
pd
Propagation Delay Time to
Logical ‘‘0’’ or ‘‘1’’
V
CC
e
5.0V
V
CC
e
10V
200
300
ns
90
140
ns
C
IN
Input Capacitance
(Note 2)
5
pF
C
PD
*
AC Parameters are guaranteed by DC correlated testing.
Power Dissipation Capacitance
(Note 3)
50
pF
Note 1:
‘‘Absolute Maximum Ratings’’ are those values beyond which the safety of the device cannot be guaranteed. Except for ‘‘Operating Temperature Range’’
they are not meant to imply that the devices should be operated at these limits. The table of ‘‘Electrical Characteristics’’ provides conditions for actual device
operation.
Note 2:
Capacitance is guaranteed by periodic testing.
Note 3:
C
PD
determines the no load AC power consumption of any CMOS device. For complete explanation see 54C/74C Family Characteristics Application
NoteDAN-90.
Connection Diagram
Dual-In-Line Package
TL/F/5882–2
Top View
Order Number MM54C42 or MM74C42
Physical Dimensions
inches (millimeters)
Ceramic Dual-In-Line Package (J)
Order Number MM54C42J or
MM74C42J
NS Package Number J16A
3
