MLX90308CAB
Programmable Sensor Interface
MLX90308CAB Programmable Sensor Interface
Page 4
Rev 1.1
11/Sept/00
Table 1. MLX90308 Electrical Specifications (continued)
DC operating parameters: TA = -40 to 140
oC, V
DD = 6 to 35VDC (unless otherwise specified).
Parameter
Test Conditions
Min
Typ
Max
Units
Temperature Sensor & Amplifier (continued).
Input voltage range TMP pin
DARDIS = 0,GNTP[1,0] = 00
325
490
mV
@ VDD = 5.0V *
DARDIS = 0,GNTP[1,0] = 01
230
345
mV
DARDIS = 0,GNTP[1,0] = 10
160
245
mV
DARDIS = 0,GNTP[1,0] = 11
113
170
mV
Input voltage range TMP pin
DARDIS = 1,GNTP[1,0] = 00
205
490
mV
@ VDD = 5.0V *
DARDIS = 1,GNTP[1,0] = 01
140
345
mV
DARDIS = 1,GNTP[1,0] = 10
100
245
mV
DARDIS = 1,GNTP[1,0] = 11
70
170
mV
DAC
Resolution
10
Bit
Monotonicity
Guaranteed By Design
Ratiometric output range (DAC output)
* DARDIS = 0
29
71
% VDD
* DARDIS = 1
1
71
% VDD
Offset Error
* DARDIS = 1
10
LSB
Differential non-linearly
1
LSB
Integral non-linearity
2
LSB
Storage capacitors
OFC buffer, digital mode buffer
7
13
pF
Settling time
MODSEL[1:0] = 1X
2
8
ms
ADC
Resolution
10
Bit
Monotonicity
Guaranteed by design
Ratiometric input range
* DARDIS = 0
29
71
% VDD
* DARDIS = 1
1
71
% VDD
Offset error
* DARDIS = 1
10
LSB
Differential non-linearly
1
LSB
Integral non-linearity
2
LSB
Conversion time
TURBO = 0
110
ì s
TURBO=1
75
ì s
Note: DARDIS is only accessible when writing custom firmware. For the MLX90308CAB, DARDIS is fixed to 1.
