NTAG203_SDS
All information provided in this document is subject to legal disclaimers.
NXP B.V. 2011. All rights reserved.
Product short data sheet
COMPANY PUBLIC
Rev. 3.0 — 19 October 2011
218630
2 of 10
NXP Semiconductors
NTAG203
NFC Forum Type 2 Tag compliant IC with 144 bytes user memory
1.2 Naming conventions
Table 1.
Family name
NTAG
2
0
3
2. Features and benefits
2.1 RF Interface (ISO/IEC 14443A)
Contactless transmission of data and supply energy (no battery needed)
Operating distance: up to 100 mm (depending on field strength and antenna geometry)
Operating frequency: 13.56 MHz
Fast data transfer: 106 kbit/s
High data integrity: 16-bit CRC, parity, bit coding, bit counting
True anticollision
7 byte serial number (cascade level 2 according to ISO/IEC 14443-3)
2.2 EEPROM
168 bytes of total memory, divided in 42 pages (4 bytes each)
144 bytes of user r/w memory area, divided in 36 pages (4 bytes each)
Field programmable read-only locking function per page for first 64 bytes
Field programmable read-only locking function per block
32-bit user definable One-Time Programmable (OTP) area
16-bit counter
Data retention of 5 years
Write endurance 10000 cycles
2.3 NFC Forum Tag 2 Type compliance
NTAG203 IC provides full compliance to the NFC Forum Tag 2 Type technical
specification (see
Ref. 11
) and enables NDEF data structure configurations (see
Ref. 12
).
2.4 Security
Anti-cloning support by unique 7-byte serial number for each device
32-bit user programmable OTP area
Field programmable read-only locking function per page for first 512 bits
Read-only locking per block for rest of memory
Short naming convention (for easier product identification)
Description
NXP NFC Tag product family name
Platform indicator
Generation number (starting from 0)
Code number for memory size
(0 : < 64 bytes, 1 : 64-96 bytes; 2 : 96-128 bytes; 3 : 128-256 bytes)
Delivery option:
if stated, it is a HWSON8 package with Field Detection pin
F
