MRC circuit
If there is no AC noise on pin 32:
V27 will be about 2.5 V for an antenna input of 60 dB or higher.
Since the MRC noise amplifier gain is fixed, the MRC circuit is adjusted by reducing the AC input level.
The MRC circuit attack and release times are determined by the capacitor C27 on pin 27.
Attack: 7 A
× C27
Release: 500
× C27
5. FM Soft Muting
By comparing the pin 47 mute on adjustment voltage to the S-meter voltage (V24), the muting on point can be adjusted.
No. 5724-24/38
LA1780M
S-meter
FM
S-meter
To SNC
Pin 28
Noise amplifier
fc = The MPF + AMP 70 kHz
Required external transistor: 2SC536 or equivalent
Reason: Since the LA1780M MRC is a simplified
circuit, an OMRC level shifter is required.
V24 = V27 – VBE
↑
QMRC
Smaller R47
Larger R47
Larger
R47
Smaller R47
