Philips Semiconductors
ISP1102
Advanced USB transceiver
Product data
Rev. 03 — 02 September 2003
3 of 23
9397 750 11228
Koninklijke Philips Electronics N.V. 2003. All rights reserved.
6.
Pinning information
6.1 Pinning
6.2 Pin description
Fig 2.
Pin configuration HBCC16.
Fig 3.
Pin configuration HVQFN14.
004aaa209
Bottom view
ISP1102W
S
V
RCV
VP/VPO
OE
D
+
D
V
n.c.
VM/VMO
S
n
V
Vreg(3.3)
n.c.
13
14
15
16
8
7
6
12
11
10
9
2
1
3
4
5
GND
(exposed diepad)
V
004aaa208
Bottom view
ISP1102BS
S
V
RCV
VP/VPO
OE
D
+
D
V
V
S
V
V
7
GND
(exposed diepad)
V
n.c.
4
5
6
3
2
1
8
9
10
11
12
13
14
Table 2:
Symbol
[1]
Pin description
Pin
HBCC16
1
Type
Description
HVQFN14
1
OE
I
input for output enable (CMOS level with respect to V
CC(I/O)
, active LOW);
enables the transceiver to transmit data on the USB bus
input pad; push pull; CMOS
differential data receiver output (CMOS level with respect to V
CC(I/O)
);
driven LOW when input SUSPND is HIGH; the output state of RCV is
preserved and stable during an SE0 condition
output pad; push pull; 4 mA output drive; CMOS
single-ended D+ receiver output VP (CMOS level with respect to V
CC(I/O)
);
for external detection of SE0, error conditions, speed of connected device;
this pin also acts as the drive data input VPO; see
Table 3
and
Table 4
bidirectional pad; push-pull input; three-state output; 4 mA output drive;
CMOS
single-ended D
receiver output VM (CMOS level with respect to V
CC(I/O)
);
for external detection of SE0, error conditions, speed of connected device;
this pin also acts as the drive data input VMO; see
Table 3
and
Table 4
bidirectional pad; push-pull input; three-state output; 4 mA output drive;
CMOS
suspend input (CMOS level with respect to V
CC(I/O)
); a HIGH level enables
low-power state while the USB bus is inactive and drives output RCV to a
LOW level
input pad; push pull; CMOS
RCV
2
2
O
VP/VPO
3
3
I/O
VM/VMO
4
4
I/O
SUSPND
5
5
I
