參數資料
型號： ISL84716IHZ-T
廠商： INTERSIL CORP
元件分類： 運動控制電子
英文描述： Ultra Low ON-Resistance, Low Voltage, Single Supply, SPST Analog Switches
中文描述： 1-CHANNEL, SGL POLE SGL THROW SWITCH, PDSO5
封裝： LEAD FREE, PLASTIC, MO-203-AA, SC-70, 5 PIN
文件頁數： 3/10頁
文件大?。?/td> 338K
代理商： ISL84716IHZ-T
3
Absolute Maximum Ratings
Thermal Information
V+ to GND . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -0.3 to 4.8V
Input Voltages
NO, NC, IN (Note 2). . . . . . . . . . . . . . . . . . . . . -0.3 to ((V+) + 0.3V)
Output Voltages
COM (Note 2). . . . . . . . . . . . . . . . . . . . . . . . . . -0.3 to ((V+) + 0.3V)
Continuous Current NO, NC, or COM . . . . . . . . . . . . . . . . .
±
300mA
Peak Current NO, NC, or COM
(Pulsed 1ms, 10% Duty Cycle, Max)
. . . . . . . . . . . . . . . . . . . ±
600mA
ESD Rating:
HBM
>
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .>4kV
MM
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .>300V
CDM. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .>1000V
Operating Conditions
Temperature Range
ISL8471XIH . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -40°C to 85°C
Thermal Resistance (Typical, Note 3)
5 Ld SC70 Package. . . . . . . . . . . . . . . . . . . . . . . . .
Maximum Junction Temperature (Plastic Package). . . . . . . . 150°C
Maximum Storage Temperature Range . . . . . . . . . . . . . -65°C to 150°C
Maximum Lead Temperature (Soldering 10s) . . . . . . . . . . . . 300°C
(Lead Tips Only)
θ
JA
(°C/W)
660
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
NOTES:
2. Signals on NC, NO, IN, or COM exceeding V+ or GND are clamped by internal diodes. Limit forward diode current to maximum current ratings.
3.
θ
JA
is measured with the component mounted on a high effective thermal conductivity test board in free air. See Tech Brief TB379 for details.
Electrical Specifications - 3V Supply
Test Conditions: V+ = +2.7V to +3.6V, GND = 0V, V
INH
= 1.4V, V
INL
= 0.5V (Notes 4, 6),
Unless Otherwise Specified
PARAMETER
TEST CONDITIONS
TEMP
(°C)
(NOTE 5)
MIN
TYP
(NOTE 5)
MAX
UNITS
ANALOG SWITCH CHARACTERISTICS
Analog Signal Range, V
ANALOG
ON Resistance, R
ON
Full
0
-
V+
V
V+ = 2.7V, I
COM
= 100mA, V
NO
or V
NC
= 1.5V
(See Figure 4)
25
-
0.26
0.4
Full
-
-
0.45
R
ON
Flatness, R
FLAT(ON)
V+ = 2.7V, I
COM
= 100mA, V
NO
or V
NC
= 0.6V, 1.5V,
2.1V (Note 7)
25
-
0.038
0.07
Full
-
-
0.09
NO or NC OFF Leakage Current,
I
NO(OFF)
or I
NC(OFF)
V+ = 3.3V, V
COM
= 0.3V, 3V, V
NO
or V
NC
= 3V, 0.3V
25
-3
-
3
nA
Full
-20
-
20
nA
COM OFF Leakage Current,
I
COM(OFF)
V+ = 3.3V, V
COM
= 0.3V, 3V, V
NO
or V
NC
= 3V, 0.3V
25
-3
-
3
nA
Full
-20
-
20
nA
COM ON Leakage Current,
I
COM(ON)
V
+
= 3.3V, V
COM
= 0.3V, 3V, or V
NO
or V
NC
= 0.3V, 3V,
or Floating
25
-3
-
3
nA
Full
-35
-
35
nA
DYNAMIC CHARACTERISTICS
Turn-ON Time, t
ON
V+ = 2.7V, V
NO
or V
NC
= 1.5V, R
L
= 50
, C
L
= 35pF
(See Figure 1, Note 8)
25
-
9
12
ns
Full
-
-
15
ns
Turn-OFF Time, t
OFF
V+ = 2.7V, V
NO
or V
NC
= 1.5V, R
L
= 50
, C
L
= 35pF
(See Figure 1, Note 8)
25
-
5
8
ns
Full
-
-
11
ns
Charge Injection, Q
V
G
= V+/2, R
G
= 0
,C
L
= 1.0nF (See Figure 2)
R
L
= 50
, C
L
= 5pF, f = 1MHz, V
COM
= 1V
RMS
(See Figure 3)
25
-
70
-
pC
OFF Isolation
25
-
-45
-
dB
Total Harmonic Distortion
f = 20Hz to 20kHz, V
COM
= 2V
P-P
, R
L
= 32
f = 1MHz, V
NO
or V
NC
= V
COM
= 0V (See Figure 5)
f = 1MHz, V
NO
or V
NC
= V
COM
= 0V (See Figure 5)
25
-
0.003
-
%
NO or NC OFF Capacitance, C
OFF
COM OFF Capacitance,
C
COM(OFF)
COM ON Capacitance, C
COM(ON)
25
-
68
-
pF
25
-
68
-
pF
f = 1MHz, V
NO
or V
NC
= V
COM
= 0V (See Figure 5)
25
-
160
-
pF
ISL84715, ISL84716
