Pad Coordinates
Unit: m
Pad No.
X
Y
Pad No.
X
Y
1
962.50
600.00
23
834.10
754.00
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
962.50
962.50
962.50
962.50
962.50
962.50
962.50
962.50
962.50
962.50
689.60
460.45
344.25
242.85
141.45
40.05
61.35
162.75
264.15
365.55
466.95
495.00
380.20
275.20
107.20
235.60
366.00
471.00
576.00
681.00
786.00
772.45
595.30
595.30
595.30
595.30
595.30
595.30
595.30
595.30
595.30
595.30
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
834.10
834.10
834.10
834.10
834.10
834.10
987.30
987.30
987.30
987.30
610.30
508.90
407.50
306.10
204.70
103.30
1.90
99.50
200.90
317.10
624.50
652.60
551.20
449.80
348.40
247.00
145.60
0.50
130.50
382.05
734.05
594.40
594.40
594.40
594.40
594.40
594.40
594.40
594.40
594.40
594.40
756.80
Pin Description
Pin No.
Pin Name
I/O
Description
1~4
LED3~LED0
O
LED driver output ports. This is a CMOS output pin and maximum driving
current up to +20mA.
5
OSC
I
Connected to an external resistor or an RC oscillator circuit.
6
DO
O
Data output pin, output serial data at falling edge of shift clock, starting from
the lower bit. This is N-ch open-drain output pin.
7
DI
I
Data input pin, input serial data at rising edge of shift clock, starting from the
lower bit.
8
CLK
I
Clock input pin. Reads serial data at the rising edge, and outputs data at the
falling edge.
9
CS
I
Initializes serial interface at the rising or falling edge of the HT16515. Then
it waits to receive a command. Data input after CS has fallen is processed,
current processing is stopped, and the serial interface is initialized. While
CS is high, CLK is ignored.
10, 11
Key0, Key1
I
Key-in data input to these pins are latched at the end of the display cycle.
12, 44
VSS
Negative power supply, ground
13, 43
VDD
Positive power supply
14~29
Seg1/KS1~Seg16/KS16
O
High voltage output, segment output pins, dual function as key source. This
is PMOS open-drain and pull-low resistor output.
30
VEE
VFD power supply
31~38
Seg17/Grid12~
Seg24/Grid5
O
High voltage output, these pins are selectable for segment or grid output.
This is PMOS open-drain and pull-low resistor output.
39~42
Grid4~Grid1
O
High voltage output, grids output pin. This is PMOS open-drain and pull-low
resistor output.
HT16515
Rev. 1.00
3
December 19, 2003
