參數資料
| 型號： | HA7-5177-5 |
| 廠商： | INTERSIL CORP |
| 元件分類： | 運動控制電子 |
| 英文描述： | 2MHz, Ultra-Low Offset Voltage Operational Amplifier |
| 中文描述： | OP-AMP, 100 uV OFFSET-MAX, 2 MHz BAND WIDTH, CDIP8 |
| 封裝： | CERDIP-8 |
| 文件頁數： | 2/10頁 |
| 文件大小： | 525K |
| 代理商： | HA7-5177-5 |
2
Absolute Maximum Ratings
Thermal Information
Supply Voltage Between V+ and V- Terminals . . . . . . . . . . . . . 44V
Differential Input Voltage . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7V
Output Current. . . . . . . . . . . . . . . . . . . . . . . .Short Circuit Protected
Operating Conditions
Temperature Range
HA-5177-2 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . -55
o
C to 125
o
C
HA-5177-5 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 0
o
C to 75
o
C
Thermal Resistance (Typical, Note 1)
CERDIP Package. . . . . . . . . . . . . . . . .
PDIP Package . . . . . . . . . . . . . . . . . . .
Maximum Junction Temperature (Ceramic Package). . . . . . . . .175
o
C
Maximum Junction Temperature (Plastic Package) . . . . . . . .150
o
C
Maximum Storage Temperature Range . . . . . . . . . -65
o
C to 150
o
C
Maximum Lead Temperature (Soldering 10s). . . . . . . . . . . . 300
o
C
(SOIC - Lead Tips Only)
θ
JA
(
o
C/W)
135
92
θ
JC
(
o
C/W)
50
N/A
CAUTION: Stresses above those listed in “Absolute Maximum Ratings” may cause permanent damage to the device. This is a stress only rating and operation of the
device at these or any other conditions above those indicated in the operational sections of this specification is not implied.
NOTE:
1.
θ
JA
is measured with the component mounted on an evaluation PC board in free air.
Electrical Specifications
V
SUPPLY
=
±
15V, Unless Otherwise Specified
PARAMETER
TEST CONDITIONS
TEMP. (
o
C)
MIN
TYP
MAX
UNITS
INPUT CHARACTERISTICS
Offset Voltage
25
-
20
60
μ
V
Full
-
40
100
μ
V
Average Offset Voltage Drift
Full
-
0.2
0.6
μ
V/
o
C
Bias Current
25
-
1.2
6
nA
Full
-
2.4
8
nA
Bias Current Average Drift
Full
-
15
35
pA/
o
C
Offset Current
25
-
0.6
6
nA
Full
-
1.0
8
nA
Offset Current Average Drift
Full
-
1.5
50
pA/
o
C
Common Mode Range
Full
±
12
-
-
V
Differential Input Resistance
25
-
47
-
M
Input Noise Voltage
0.1Hz to 10Hz
25
-
0.35
0.6
μ
V
P-P
Input Noise Voltage Density
f
O
= 10Hz
25
-
13
18
nV/
√
Hz
f
O
= 100Hz
25
-
10
13
nV/
√
Hz
f
O
= 1000Hz
25
-
9
11
nV/
√
Hz
Input Noise Current
0.1Hz to 10Hz
25
-
14
45
pA
P-P
Input Noise Current Density
f
O
= 10Hz
25
-
7.1
10
pA/
√
Hz
f
O
= 100Hz
25
-
3.3
5
pA/
√
Hz
f
O
= 1000Hz
25
-
1.2
2
pA/
√
Hz
TRANSFER CHARACTERISTICS
Large Signal Voltage Gain (Note 2)
25
126
150
-
dB
Full
120
140
-
dB
Common Mode Rejection Ratio (Note 3)
Full
110
140
-
dB
Closed Loop Bandwidth
A
VCL
= +1
25
0.6
2
-
MHz
HA-5177
