參數資料
型號： FTLF1721S1GCL
元件分類： 光收發
英文描述： FIBER OPTIC TRANSCEIVER, 1280-1335nm, 2667Mbps(Tx), 2667Mbps(Rx), THROUGH HOLE MOUNT, LC CONNECTOR
文件頁數： 6/12頁
文件大?。?/td> 209K
代理商： FTLF1721S1GCL
FTLF1721S1xCL 2x10 Pin SFF Product Specification – March 2006
F i n i s a r
Finisar Corporation March 2006 Rev A
Page 3
II.
Absolute Maximum Ratings
Parameter
Symbol
Min
Typ
Max
Unit
Notes
Maximum Supply Voltage
Vcc
-0.5
4.5
V
Storage Temperature
TS
-40
85
°C
Case Operating Temperature
TOP
-10
70
°C
Relative Humidity
RH
0
85
%
1
Lead Soldering Temperature/Time
260/10
°C/s
III.
Electrical Characteristics (TOP = -10 to 70 °C, VCC = 3.00 to 3.60 Volts)
Parameter
Symbol
Min
Typ
Max
Unit
Notes
Supply Voltage
Vcc
3.00
3.60
V
Supply Current
Icc
270
340
mA
Transmitter
Input differential impedance
Rin
100
2
Single ended data input swing
Vin,pp
250
1200
mV
Transmit Disable Voltage
VD
Vcc – 1.3
Vcc
V
Transmit Enable Voltage
VEN
Vee
Vee+ 0.8
V
3
Transmit Disable Assert Time
10
us
Receiver
Single ended data output swing
Vout,pp
300
400
800
mV
4
Data output rise time
tr
100
175
ps
5
Data output fall time
tf
100
175
ps
5
SD Assert
VSD assert
Vcc – 0.5
Vcc
V
6
SD De-Assert
VSD deassert
Vee
Vee+0.5
V
6
Power Supply Rejection
PSR
100
mVpp
7
Total Generated Receiver Jitter
(peak to peak)
JRXp-p
0.07
UI
8
Total Generated Receiver Jitter
(rms)
JRXrms
0.007
UI
8
Notes:
1.
Non condensing.
2.
AC coupled.
3.
Or open circuit.
4.
Into 100 ohms differential termination.
5.
20 – 80 %
6.
Signal Detect is LVTTL. Logic 0 indicates normal operation; logic 1 indicates no signal detected.
7.
All transceiver specifications are compliant with a power supply sinusoidal modulation of 20 Hz to 1.5
MHz up to specified value applied through the power supply filtering network shown on page 23 of the
Small Form-factor Pluggable (SFP) Transceiver MultiSource Agreement (MSA)
2, September 14, 2000.
8.
Parameters per GR-253
2 section 5.6 for OC-48B.
相關PDF資料
PDF描述
FTLF1721S1HCL FIBER OPTIC TRANSCEIVER, 1280-1335nm, 2667Mbps(Tx), 2667Mbps(Rx), THROUGH HOLE MOUNT, LC CONNECTOR
FTLF1721S1MCL FIBER OPTIC TRANSCEIVER, 1280-1335nm, 2667Mbps(Tx), 2667Mbps(Rx), THROUGH HOLE MOUNT, LC CONNECTOR
FTLF1721S1KCL FIBER OPTIC TRANSCEIVER, 1280-1335nm, 2667Mbps(Tx), 2667Mbps(Rx), THROUGH HOLE MOUNT, LC CONNECTOR
FTLF8519P2BNL FIBER OPTIC TRANSCEIVER, 830-860nm, 2125Mbps(Tx), 2125Mbps(Rx), PANEL MOUNT, LC CONNECTOR
FTLF8519P2WNL FIBER OPTIC TRANSCEIVER, 830-860nm, 2125Mbps(Tx), 2125Mbps(Rx), PANEL MOUNT, LC CONNECTOR
相關代理商/技術參數
參數描述
FTLF1721S1HCL 制造商:Finisar Corporation 功能描述:SAME AS FTLF1721S1MCL, BUT LONG EMI SHIELD - Trays 制造商:Finisar Corporation 功能描述:TXRX 1310NM DFB APD 1X/2X SFF
FTLF1721S1KCL 制造商:Finisar Corporation 功能描述:SAME AS FTLF1721S1MCL, BUT 2 GROUND PINS & LONG EMI SHIELD - Trays 制造商:Finisar Corporation 功能描述:TXRX 1310NM DFB APD 1X/2X SFF
FTLF1721S1MCL 制造商:Finisar Corporation 功能描述:TX/RX OPTICAL FIBER 2667MBPS - Trays 制造商:Finisar Corporation 功能描述:TXRX 1310NM DFB APD 1X/2X SFF
FTLF1721S1XCL 制造商:FRONTIER 制造商全稱:Frontier Electronics. 功能描述:Product Guide
FTLF2318P1BCL 制造商:FRONTIER 制造商全稱:Frontier Electronics. 功能描述:Product Guide
