100
Dimensions and specifications subject to change without notice.
FO-FC SERIES CONNECTORS
LC Front Shell Cleanable Adapters
Series
Front Shell (for FC rear shell)
LC - Front Shell Specific
Keying
A1 - Vertical
A2 - Horizontal
Configuration
STD - Standard
The FO-FC fiberoptic LC front shell enables a direct optical
connection between an FC connector that is mounted on the rear
shell installed in the equipment side, and an LC plug that has a
different ferrule diameter (FC connector diameter: 2.5mm; LC plug
diameter: 1.25mm). The use of a precise zirconia ceramic split sleeve
insert ensures low insertion loss and high durability.
By mounting the LC front shell to the cleanable adapter rear shell,
an LC-type optical connector with a 1.25mm ferrule diameter can be
connected. Additionally, the LC front shell is available with either a
vertical or horizontal key direction, as appropriate for the rear-side
connector.
FEATURES
Permits direct optical connection between LC plug
and FC connector with different diameters
High durability
Low insertion loss
Vertical or horizontal keying
RoHS compliant
GENERAL SPECIFICATIONS
Insertion Loss
(Includes the loss of a pair of mas-
ter plugs mated to the adapters)
Operating Temperatures
Durability
0.5dB (max.)
-40oC to +85oC
500 Cycles (min.)
ORDERING INFORMATION
FO-FC
–
FS
(LC
– AX) – STD
Connector Profile (Ref.)
