October 2001
FDW2503NZ
Dual N-Channel 2.5V Specified PowerTrench
ò
MOSFET
2001 Fairchild Semiconductor Corporation
FDW2503NZ Rev C(W)
General Description
This NChannel 2.5V specified MOSFET is a rugged
gate version of Fairchild Semiconductor’s advanced
PowerTrench process. It has been optimized for power
management applications with a wide range of gate
drive voltage (2.5V – 12V).
Applications
Load switch
Motor drive
DC/DC conversion
Power management
Features
5.5 A, 20 V.
R
DS(ON)
= 20 m
@ V
GS
= 4.5V
R
DS(ON)
= 26 m
@ V
GS
= 2.5V
Extended V
GSS
range (±12V) for battery applications
ESD protection diode (note 3)
High performance trench technology for extremely
low R
DS(ON)
Low profile TSSOP-8 package
8
7
6
5
1
2
3
4
Absolute Maximum Ratings
T
A
=25
o
C unless otherwise noted
Symbol
Parameter
V
DSS
Drain-Source Voltage
V
GSS
Gate-Source Voltage
I
D
Drain Current – Continuous
– Pulsed
P
D
Power Dissipation
T
J
, T
STG
Operating and Storage Junction Temperature Range
Ratings
20
±
12
5.5
30
1.0
0.6
–55 to +150
Units
V
V
A
W
°
C
(Note 1a)
(Note 1a)
(Note 1b)
Thermal Characteristics
R
θ
JA
Thermal Resistance, Junction-to-Ambient
Package Marking and Ordering Information
Device Marking
Device
2503NZ
FDW2503NZ
(Note 1a)
(Note 1b)
100
125
°
C/W
Reel Size
13’’
Tape width
12mm
Quantity
3000 units
F
